Xilinx ZCU104 User Manual

ZCU104 Board User Guide 15
UG1267 (v1.1) October 9, 2018 www.xilinx.com
Chapter 2: Board Setup and Configuration
Default Jumper and Switch Settings
Figure 2-1 shows the ZCU104 board jumper header and DIP switch locations. Each
numbered component shown in the figure is keyed to Table 2-2 (for default jumper
settings) or Table 2-3 (for default switch settings). Both tables reference the respective
schematic page numbers.
Jumpers
Table 2-2: Default Jumper Settings
Number Ref. Des. Function Default
Schematic
Page
33 J85
POR_OVERRIDE
• 1-2: Enable
•2-3: Disable
2-3 3
34 J12
SYSMON I2C address
• Open: SYSMON_VP_R floating
• 1-2: SYSMON_VP_P pulled down
1-2 3
34 J13
SYSMON I2C address
• Open: SYSMON_VN_R floating
• 1-2: SYSMON_VP_N pulled down
1-2 3
35 J20
Reset sequencer PS_POR_B
• Open: Sequencer does not control
PS_POR_B
• 1-2: Sequencer can control PS_POR_B
1-2 12
35 J21
Reset sequencer PS_SRST_B
• Open: Sequencer does not control
PS_SRST_B
• 1-2: Sequencer can control PS_SRST_B
1-2 12
35 J22
Reset sequencer inhibit
• Open: Sequencer normal operation
• 1-2: Sequencer inhibit (resets stay
asserted)
Open 12
