ZCU104 Board User Guide 77
UG1267 (v1.1) October 9, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-29: J5 LPC FMC Section C and D Connections to XCZU7EV U1
J5
Pin
Schematic Net Name
I/O
Standard
U1
FPGA
Pin
J5
Pin
Schematic Net Name
I/O
Standard
U1
FPGA
Pin
C2 FMC_LPC_DP0_C2M_P
(2)
H4 D1 VADJ_FMC_PGOOD
C3 FMC_LPC_DP0_C2M_N
(2)
H3 D4 FMC_LPC_GBTCLK0_M2C_P
(1)
LVDS V8
C6 FMC_LPC_DP0_M2C_P
(2)
G2 D5 FMC_LPC_GBTCLK0_M2C_N
(1)
LVDS V7
C7 FMC_LPC_DP0_M2C_N
(2)
G1 D8 FMC_LPC_LA01_CC_P LVDS H18
C10 FMC_LPC_LA06_P LVDS H19 D9 FMC_LPC_LA01_CC_N LVDS H17
C11 FMC_LPC_LA06_N LVDS G19 D11 FMC_LPC_LA05_P LVDS K17
C14 FMC_LPC_LA10_P LVDS L15 D12 FMC_LPC_LA05_N LVDS J17
C15 FMC_LPC_LA10_N LVDS K15 D14 FMC_LPC_LA09_P LVDS H16
C18 FMC_LPC_LA14_P LVDS C13 D15 FMC_LPC_LA09_N LVDS G16
C19 FMC_LPC_LA14_N LVDS C12 D17 FMC_LPC_LA13_P LVDS G15
C22 FMC_LPC_LA18_CC_P LVDS D11 D18 FMC_LPC_LA13_N LVDS F15
C23 FMC_LPC_LA18_CC_N LVDS D10 D20 FMC_LPC_LA17_CC_P LVDS F11
C26 FMC_LPC_LA27_P LVDS A8 D21 FMC_LPC_LA17_CC_N LVDS E10
C27 FMC_LPC_LA27_N LVDS A7 D23 FMC_LPC_LA23_P LVDS B11
C30 FMC_LPC_IIC_SCL D24 FMC_LPC_LA23_N LVDS A11
C31 FMC_LPC_IIC_SDA D26 FMC_LPC_LA26_P LVDS B9
C34 GND D27 FMC_LPC_LA26_N LVDS B8
C35 VCC12_SW D29 F4232_TCK
C37 VCC12_SW D30 FPGA_TDO_FMC_TDI_LS
C39 UTIL_3V3 D31 FMC_TDO
D32 UTIL_3V3
D33 FT4232_TMS
D34 NC
D35 GA1=0=GND
D36 UTIL_3V3
D38 UTIL_3V3
D40 UTIL_3V3
Notes:
1. Series capacitor coupled.
2. MGT connections I/O standard not applicable.
