Chapter 3: Board Component Descriptions
AH24 DDR4_DM2 E7 DML_B/DBIL_B U99
AJ29 DDR4_DM3 E2 DMU_B/DBIU_B U99
AD29 DDR4_DM4 E7 DML_B/DBIL_B U100
Y29 DDR4_DM5 E2 DMU_B/DBIU_B U100
AC32 DDR4_DM6 E7 DML_B/DBIL_B U2
Y32 DDR4_DM7 E2 DMU_B/DBIU_B U2
AN26 DDR4_DQS0_T G3 DQSL_T U101
AN27 DDR4_DQS0_C F3 DQSL_C U101
AN29 DDR4_DQS1_T B7 DQSU_T U101
AP30 DDR4_DQS1_C A7 DQSU_C U101
AH26 DDR4_DQS2_T G3 DQSL_T U99
AJ26 DDR4_DQS2_C F3 DQSL_C U99
AK28 DDR4_DQS3_T B7 DQSU_T U99
AK29 DDR4_DQS3_C A7 DQSU_C U99
AD30 DDR4_DQS4_T G3 DQSL_T U100
AD31 DDR4_DQS4_C F3 DQSL_C U100
Y27 DDR4_DQS5_T B7 DQSU_T U100
Y28 DDR4_DQS5_C A7 DQSU_C U100
AB33 DDR4_DQS6_T G3 DQSL_T U2
AB34 DDR4_DQS6_C F3 DQSL_C U2
W31 DDR4_DQS7_T B7 DQSU_T U2
W32 DDR4_DQS7_C A7 DQSU_C U2
AL31 DDR4_CK_T K7 CK_T U2,U99-U101
AN32 DDR4_CK_C K8 CK_C U2,U99-U101
AN33 DDR4_CKE K2 CKE U2,U99-U101
AP32 DDR4_ODT K3 ODT U2,U99-U101
AF28 DDR4_A16_RAS_B L8 RAS_B/A16 U2,U99-U101
AG28 DDR4_A15_CAS_B M8 CAS_B_A15 U2,U99-U101
AG29 DDR4_A14_WE_B L2 WE_B/A14 U2,U99-U101
AE25 DDR4_ACT_B L3 ACT_B U2,U99-U101
AB26 DDR4_ALERT_B P9 ALERT_B U2,U99-U101
AA26 DDR4_PAR T3 PAR U2,U99-U101
AD26 DDR4_RESET_B P1 RESET_B U2,U99-U101
Table 3-3: DDR4 Component Memory Connection to XCZU7EV PS Bank 504 (Cont’d)
XCZU7EV (U1)
Pin
Net Name
DDR4 Component Memory
Pin # Pin Name Ref. Des.
