ZCU104 Board User Guide 41
UG1267 (v1.1) October 9, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
The M.2 U170 connector pinout is listed in Table 3-9.
Table 3-9: M.2 Connector U170 Pinout
Pin Signal
74 3.3V
72 3.3V
70 3.3V
68 SUSCLK(32 kHz) (I)(0/3.3V)
ADD_IN CARD KEY M
ADD_IN CARD KEY M
ADD_IN CARD KEY M
ADD_IN CARD KEY M
58 Reserved for MGFG_CLOCK
56 Reserved for MGFG_DATA
54 NC
52 NC
50 NC
48 NC
46 NC
44 ALERT# (O) (0/1.8V)
42 SMB_DATA (I/O) (0/1.8V)
40 SMB_CLK (I/O) (0/1.8V)
38 DEVSLP (I)
36 NC
34 NC
32 NC
30 NC
28 NC
26 NC
24 NC
22 NC
20 NC
18 3.3V
16 3.3V
14 3.3V
12 3.3V
10 DAS/DSS (I/O)
To Next Page
