Chapter 3: Board Component Descriptions
Table 3-22: HDMI Connections to MPSoC U1
XCZU7EV
(U1) Pin
Schematic Net Name I/O Standard
Connected Component
Pin Name Device
M4 HDMI_TX0_P
(1)
8IN_D0P
SN65DP159 (U94)
Wired to top port (P7)
M3 HDMI_TX0_N
(1)
9IN_D0N
L6 HDMI_TX1_P
(1)
5IN_D1P
L5 HDMI_TX1_N
(1)
6IN_D1N
K4 HDMI_TX2_P
(1)
2IN_D2P
K3 HDMI_TX2_N
(1)
3IN_D2N
H9 HDMI_TX_LVDS_OUT_P LVDS 11 IN_CLKP
G9 HDMI_TX_LVDS_OUT_N LVDS 12 IN_CLKN
B1 HDMI_TX_SRC_SCL LVCMOS33 46 SCL_SRC
C1 HDMI_TX_SRC_SDA LVCMOS33 47 SDA_SRC
A2 HDMI_TX_EN LVCMOS33 42 OE
A3 HDMI_TX_CEC LVCMOS33 24 CEC_A
TPD12S016RK (U70)
E3 HDMI_TX_HPD LVCMOS33 3 HPD_A
N11 HDMI_SI5324_LOL LVCMOS33 18 LOL
SI5319C (U108)
M12 HDMI_SI5324_RST LVCMOS33 1 RST_B
G14 HDMI_REC_CLOCK_C_P LVDS 16 CKIN1_P
F13 HDMI_REC_CLOCK_C_N LVDS 17 CKIN1_N
T8 HDMI_SI5324_OUT_C_P
(1)
28 CKOUT1_P
T7 HDMI_SI5324_OUT_C_N
(1)
29 CKOUT1_N
N2 HDMI_RX0_C_P
(1)
29 OUT_D0P
TMDS181IRGZT (U19)
Wired to HDMI
bottom port(P7)
M3 HDMI_RX0_C_N
(1)
28 OUT_D0N
L2 HDMI_RX1_C_P
(1)
32 OUT_D1P
L1 HDMI_RX1_C_N
(1)
31 OUT_D1N
J2 HDMI_RX2_C_P
(1)
35 OUT_D2P
J1 HDMI_RX2_C_N
(1)
34 OUT_D2N
R10 HDMI_RX_CLK_C_P
(1)
26 OUT_CLKP
R9 HDMI_RX_CLK_C_N
(1)
25 OUT_CLKN
F6 HDMI_RX_HPD LVCMOS33 33 HPD_SNK
E5 HDMI_RX_PWR_DET LVCMOS33 3 D Q6
D1 HDMI_CTL_SCL LVCMOS33 15 SCL_CTL
(2)
E1 HDMI_CTL_SDA LVCMOS33 16 SDA_CTL
