Xinje DS3E Series User Manual

9999
13
Numerator of Electronic gear ratio
-
1
1~
65535
√
6
5-3-3
14
Denomination of electronic gear ratio
-
1
1~
65535
√
6
5-3-3
15
Pulse frequency corresponding to
speed mode rated speed
*100
Hz
1000
0~
10000
○
7
5-6-3
16
Speed command pulse filter time
0.01ms
100
0~
10000
○
7
5-6-4
18
Encoder feedback pulse per circle×1
1
2500
0~9999
○
All the
modes
5-11-6
19
Encoder feedback pulse per
circle×10000
10000
0
0~
9999
○
All the
modes
5-11-6
20
Encoder pulse frequency division
(numerator)
-
1
0~
65535
○
All the
modes
5-11-6
21
Encoder pulse frequency division
(denomination)
-
1
0~
65535
○
All the
modes
5-11-6
23
Pulse offset limit
*256
command
unit
50000
0~
65535
√
6
5-3-9
24
Discharge resistor type
0: internal
1: external
-
0
0~1
○
All the
modes
3-4
25
Discharge resistor power
W
-
0~
65535
√
All the
modes
3-4
26
Discharge resistor value
Ω
-
0~
500
√
All the
modes
3-4
27
Servo OFF stop mode
0: inertia running stop, keep the
inertia running state after stop
2: deceleration running stop, keep
inertia running state after stop
-
0
0, 2
○
All the
modes
5-2-3
28
Servo over range stop mode
0: deceleration stop, over range
direction torque is 0 after stop,
receive command
1: inertia stop, over range direction
torque is 0 after stop, receive
command
2: deceleration stop, over range
direction not receive command after
stop
3: alarm (E-260)
-
2
0~3
○
All the
modes
5-2-3
29
Servo alarm stop mode
0: inertia stop, keep inertia running
state after stop
2: deceleration stop, keep inertia
running state after stop
-
0
0, 2
○
All the
modes
5-2-3
30
Stop overtime time
0.1ms
20000
0~
65535
○
All the
modes
5-2-3
33
Motor code
-
0~
65535
●
All the
modes
4-7
70
Motor locked rotor time
s
0
0~9999
○
All the
modes
71
Motor locked rotor speed
rpm
0
0~9999
○
All the
modes
