MS6S-80C□20B□□-20P7
127
160
MS6H-80C□30B□□-20P7
124
157
High inertia
MS6H-80C□20B□□-20P7
149
182
8
3
25
70h7
19h6
35
LA
Ø90
80
4-Ø6.50
M5深10
15.5
6
N9
49.3
48.8
67.05
99.25
0.06 A
0.02 A
0.04 A
A
1
Motor model
LA±1
Inertia level
Normal
With
brake
MS6S-80C□30B□3-20P7
107.1
132.1
Low inertia
MS6H-80C□30B□3-20P7
107.1
132.1
High inertia
MS6S-80C□30B□3-21P0
117.6
142.6
Low inertia
MS6H-80C□30B□3-21P0
134
159
High inertia
◼ 100 series motor installation dimensions Unit: mm
154.5
45
125
95h7
Ø22h6
32
A
A
4-∅9
□ 100
8
N9
18
A-A
0.1 A
A
0.03 A
0.06 A
60.77
94.65
92.5
139.5
M6深12
2
Ø
115
Motor model
LA±1
Inertia level
Normal
With
brake
MS6S-100C□30B2-21P5
154.5
183
Low inertia
◼ 110 series motor installation dimensions Unit: mm
