Xinje TP Series User Manual

7
(2) Communicate with inverter
TP can communicate with various brands of frequency inverters. For the brands which are
not in the list, user can select Modbus protocol or user-defined protocol.
(3) Communicate with meters
About the communication between TP and meters, users can select user-defined protocol
or Modbus protocol.
1-4 Dimension and installation
1-4-1 Product dimensions
TP460-L (Unit: mm)
0.0
+0.5
0.0
+0.5
40.6
165.0
113.0
163.2
45.1
111.4
121.4
173.2
PLC com port
TP series
Mitsubishi FR series inverter
Inovance MD series inverter
Bosch Rexroth FE series
inverter
