Xinje TP Series User Manual

1
1 TP series HMI
1-1 Features
Xinje TP series HMI have strong functions. It supports multi-language, any font and size of
characters. The basic functions include data display and monitoring, alarm, recipe. It can
communicate with most brands of PLC, two ports can communicate individually. The
programming software Touchwin has friendly interface and easy to operate. The software
can simulate online and offline (SCADA function).
1-1-1 Product features
 Display
 Monochrome or 256 colors LCD, support BMP, JPG pictures display
 Support multi-language: Chinese, English, Japanese, Korean, German, French,
Arabic, etc. The fonts support any size, artistic effect, bold, italic, etc.
 Large program capacity support more program screens and data.
 Control
 Dynamic data displaying and monitoring, bar map, real-time/historical trend map,
discrete/continuous histogram, switching control;
 Real-time/historical alarm records;
 Sample and save the data at certain time or conditions;
 Nine levels password protection;
 On/off line simulation, SCADA function
 Communication
 Two ports can communicate independently, enable to connect many devices at the
same time;
 Support micro-printer
 Support free format communication, user can make the communication protocol
freely.
1-1-2 Model naming rule
□□○○○—□
1 2 3
1：Series name TP
2：LCD size 460:4.7’’
760:7.0’’
3：LCD display L：Monochrome LCD
T：256 colors TFT LCD
