27
Anti-jamm
ing
Voltage noise:1500Vp-p,pulse 1us1 minute
Surroundi
ng air
No corrosive gas
Protection
constructi
on
IP65
Construct
ion
Cooling
method
Natural air cooling
Exterior
dimension
(mm)
200.4*146.9*
43.4
224.4*170.8*
45.5
272.2*191.7*
51.2
410.0*270.0*
65.0
Mounting
dimension
(mm)
192.0*138.5
211.4*157.8
260.2*179.7
399.0*259.0
Interface
PLC port
RS232/RS485/RS422 (TG765-XT, TG765-XT-C only support
RS232)
Download
port
RS232/RS485 (TG765-XT and TG765-XT-C dont have this
port)
Ethernet
port
RJ45 (Only for ET series)
USB1
USB-A (accord with USB2.0), USB flash drive port
USB2
USB-B (accord with USB2.0), USB download port
3-3 Hardware
3-3-1 Hardware structure
