Xinje TP Series User Manual

26
3-2 General specifications
HMI specifications
Item
TG765
TG865
TGA62
TGC65
Screen
Size
7.0″
8.0″
10.1″
15.6’’
Type
16 million colors
Resolution
800*480
800*600
800*480
1366*768
Brightness
Adjustable (through register PFW100)
Non-adjustable
Touch panel
4-wire resistance mode
Using life
More than 50000 hours, temperature 25℃, running for 24 hours
Language
Chinese, English, Japanese, Korean, German, French,
Arabic…
Character
Any font and size
Memory
Capacity
128MB
Electric specifications
Item
TG765
TG865
TGA62
TGC65
Electric
Input
voltage
DC24V (Range: DC22V-DC26V)
Consumpt
ion current
200mA
230mA
250mA
710mA
Allowable
momentar
y power
failure
Below 10ms (Actual power failure<1s)
Withstand
voltage
AC1000V,10mA,less than 1 minute (signal and ground)
Insulated
impedanc
e
DC500V, above 10MΩ (signal and ground)
Environm
ent
Operation
temperatu
re
0-50℃
Reserve
temperatu
re
-20-60℃
Environm
ent
humidity
10%RH-90%RH（no condensation）
Withstand
oscillation
10-25HZ（X,Y,Z each direction 30 minutes 2G）

Xinje TP Series Specifications

General

Brand	Xinje
Model	TP Series
Category	Touch Panel
Language	English
