Xinje TP Series User Manual

12
TH series HMI configuration form
Series
Model
LCD
size
Resolution
(pixel)
Screen
PORT1
Download
port
PORT2
PLC port
PORT3
EXT
port
USB-A
port
Download
way
TH465
TH465-MT
4.3″
480*272
8MB
-
232/485/42
2
-
-
USB-B
TH465-UT
1
TH465-MT
2
232
-
TH465-UT
2
1
TH765-M
TH765-MT
7.0″
800*480
128M
B
232/485
232/485/42
2
-
-
TH765-UT
1
TH765-N
TH765-NT
7.0″
800*480
128M
B
232/485
232/485/42
2
-
-
TH765-NU
1
TH765-NT
3
485
(1A6B
)
-
TH765-NU
3
1
TH865
TH865-MT
8.0″
800*600
128M
B
232/485
232/485/42
2
-
-
TH865-UT
1
THA62
THA62-MT
10.1″
800*480
128M
B
232/485
232/485/42
2
-
-
THA62-UT
2
THA65
THA65-MT
10.4″
800*600
128M
B
232/485
232/485/42
2
-
-
THA65-UT
2
TH series add two kind of power-off retentive registers: PHW (520 thousand
registers) and PRW (1 thousand registers), so if user need the PHW register, user
should mark it, and TH465 doesn’t have PHW, it only has PRW.
2-2 General specifications
HMI specifications
Item
TH465
TH765
TH865
THA62
THA65
Screen
Specification
Size
4.3″
7.0″
8.0″
10.1″
10.4″
Type
65536 true colors
Resolution
480*272
800*480
800*600
800*480
800*600
Brightness
Cannot
be
adjusted
Can be
adjusted
(Hardware
version>V1.0)
Cannot
be
adjusted
Can be
adjusted
(Hardware
version>V1.0)
Cannot
be
adjusted
Touch
4-wire resistance mode
