Xinje TP Series User Manual

13
panel
Use life
More than 50000 hours, 24 hours running when surrounding
temperature is 25 ℃
Character
Chinese, English, Korean, Japanese…
Character
size
Any size and font
Memory
Screen
8MB
128MB
Electrical specifications
Item
TH465
TH765
TH865
THA62
THA65
Electrical
Input
voltage
DC24V(Range:DC22V-DC26V)
Consumptio
n current
130mA
250mA
260mA
230mA
630mA
Momentary
power off
allowance
Less than 10ms (Actual power off less than 1s)
Withstand
voltage
AC1000V，10mA，less than 1 minute(signal and ground)
Insulated
impedance
DC500V，above 10MΩ(signal and ground)
Environment
Operation
temperature
0-50℃
Reserve
temperature
-20-60℃
Humidity
10%RH-90%RH (no condensation)
Withstand
oscillation
10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jammin
g
Voltage noise: 1500Vp-p, pulse 1us, 1 minute
Surrounding
air
No corrosive gas
Protection
construction
IP65
Construction
Cooling
method
Natural air cooling
Exterior
dimension
(mm)
152.0*102.0*
41.8
204.0*150.5*
43.9
224.4*170.8*
45.5
272.2*191.7*
51.2
311.0*234.0*
48.0
Mounting
dimension
(mm)
144.0*94.0
192.0*138.5
211.4*157.8
260.2*179.7
302.0*225.0

Xinje TP Series Specifications

General

Brand	Xinje
Model	TP Series
Category	Touch Panel
Language	English
