9
Do not use TP in below environment:
Inflammable gas, steam, dust, fast vary temperature, high humidity (it may cause moisture
inside TP).
Power supply requirements:
TP series touch screen use DC +24V power supply only. The permitted voltage range is
20V~26V. The connection is as below:
Terminal type Pin type
Besides, if connect high voltage or AC power supply with TP, the TP may be damaged and
cause electric shock to human body.
NOTE: if use the DC +24V output of PLC to drive the TP, make sure the PLC
has enough current to drive the TP.
