40
Cap choices
Mandatory cleaning after using underwater
Diving greater than 20 meters deep ?
DIVING & SEALING
GRAY PLUG No. 1 = 1 m max.
This is the plug for common use on land or for a submerged
remote control up to 1 m.
A sealed membrane lets the air through but withstands 1 m
depth. It balances the internal pressure to prevent the remote
control from swelling during a variation in T° or altitude.
RED PLUG No. 2 = 20 m max.
Reserved for underwater use exclusively.
On land the red plug will not balance the internal pressure,
Before submerging more
than 1 m deep, screw in the
red plug no. 2.
Max. depth 20 m / 66ft.
Rinse the entire detector
with fresh water.
Dry the detector with a towel.
Insert the gray plug no. 1 for all
land use and up to 1 m deep
water for the remote control.
which could cause the exible keypad to swell or the loud speaker to stick during variations in T°. If this
happens and you are aware of poor sound from the loud speaker, insert the gray plug and blow through
your mouth onto the loud speaker grille to get it going again.
is designed with robust materials that can withstand salt environments. For example, the con-
nectors, fastenings and coil charging contacts are made from marine grade stainless steel. However, pre-
cautions must be taken as with any diving equipment:
!
Rinse your detector with fresh water after using it on the beach and before unscrewing the connector or plug.
!
Tighten the plugs systematically to prevent any ingress of salt water or sand in the connectors on the re-
mote control or BH-01 headphone at the risk of corroding the internal contacts. If salt water or sand has pen-
etrated, rinse the male and female contacts and the connector thoroughly with fresh water and leave to dry.
!
Never leave the remote control in direct sunlight, for example: in a hot car, especially if it is tted with the
red plug, as this may damage the loud speaker.
At a depth greater than 20 m, the screen may darken slightly in the center due to the pressure exerted by
the glass on the crystals. This can be reversed when ascending. However, the screen can break at a depth
of about 35 m/115 ft, so be careful.
20 M / 66 ft
1 M / 3 ft
Max 20 M / 66 ft
