SPECIFICATIONS
Link XP Link, Digital wireless
Channels 36 automatic channels
Radio Frequency specication
Radio link
Detection
FREQUENCY
POWER
2.40 à 2.48 GHz <2.11 dBm
3.9 à 135.7 KHz <72dBµA/m at 10m
Display screen 8192 pixels
Software updates Yes, by USB/Internet connection
Wireless Headphones optional WS6 (rainproof) - WSAII (rainproof) - WSAII XL (IP 68-1m)
Wireless coil optional DD 22.5cm-9’’/28 cm-11’’/34x28cm-13’’x11’’ (fully waterproof 20m - 66 ft)
Coil cover Ye s
Hip mount remote control case Ye s
Headphones storage case Yes (WS6, WSA II)
Stem Fully telescopic, S-shaped
Batteries Remote/Coil: 700 mAh - Headphones: 320 mAh
Battery level indicator Yes: Remote/Headphones/Coil/MI-6
Wireless Remote Control battery life ~ 15 to 30H depending on audio output activated
Wireless Headphone battery life ~ 15H WSAII/WS6
Wireless Coil battery life 8H to 20H depending on programs and frequencies
Mains power charger Depending on version, Input 100-220V 50/60Hz, Output 5V- 1A max
Cigarette lighter charger Optional
Bone conduction headphones Waterproof IP68 - 20m - 66 ft (optional)
Charging time ~3 h
Total detector weight with batteries See product page for details on each version
Stem weight 370 g (S-Telescopic) - 305 g (S-Telescopic lite)
Remote weight with battery 150 g
Headphone weight with battery WS6: 82 g - WSA II: 72 g - WSA II XL: 250 g
Coil weight 22.5cm- 9’’: 345 g - 28 cm-11’: 470 g - 34x28cm-13’’x11’’: 570 g
Length of folded stem 58 cm
Length of extended stem 130 cm
Operating T° 0 to + 40°C
Max ambient T° during charging 0 to + 40°C
Recommended storage T° 25°C
Waterproof coil IP 68 - 20m - 66 ft, *optional antenna required when the coil is submerged
Warranty Five years parts and labor. Batteries, chargers and connectors have a two-
year warranty
Patents US 7940049 B2 - EP 1990658 B1 and patents pending
Detection frequencies Simultaneous Multi Frequency (40dBµA/m at 10m) or between the 49 single
frequencies from 4 to 45 kHz.
Sensitivity 99 levels
Sound type Different sound options: PWM, SQUARE, etc.
Audio Volume 10 levels for each audio output
Reactivity 9 levels (0/0.5/1/1.5/2/2.5/3/4/5)
Audio Response 8 levels
Iron Volume 6 levels
Multi Tones 1, 2, 3, 4, 5, Pitch and Full Tones 1 and 2 + EXPERT modes
Ground balance Tracking, Grab, Manual
Multi-Notch Yes, with adjustable window width
Non-motion mode - Pinpoint Yes, with and without Autotune - Audio and visual
Discrimination Audio and visual/ferrous bottle cap rejection on 5 levels/Silencer
Threshold Threshold and Audio frequency adjustable
Equalizer 4 Bands congurable
Programs 12 factory programs + 12 users
Backlight 20 levels adjustable, very low power consumption
Radio
Features/Settings
General Features
