Xplore iX104C5 - Page 110

EMC
CFR 47, FCC part 15B, IC ICES-003,
European Union Directive 2004/108/EC RTT&E
301 489-17
Safety
TUV Bauart, RoHS 2002/95/EC, WEEE
IEC600950-1 2
nd
Ed, EN60950-1 2
nd
Ed, UL60950-1 2
nd
Ed: CB scheme with CE Mark.
UL1604, ATEX, IECEX
ETL Listed: ANSIISA-12.12.01-2007, C22.2 No. 213
M1987
Appendix D. Hardware Specifications
Environmental (continued)
Enclosure Class Blowing rain:
4”/hr, 40 mph wind and
MIL-STD-810G Method 506.4 Procedure 1
Drip:
7 gal/ft2/hr
MIL-STD-810G Method 506.4 Procedure III
Sand and dust:
Particle size < 149 µm, 10 + 7 g/m3 particle
density 1.5 m/s
to 8.9 m/s wind speed
MIL-STD-810G Method 510.4 Procedure 1
Salt Fog:
5% saline for 48 hr (12 hr wet, 12 hr dry, 2
cycles)
MIL-STD-810G Method 509.4
Contamination by fluids:
Detergents, brake fluid, aromatic hydrocarbons
MIL-STD-810G Method 504
Solar radiation:
1120 W/m2 (355 Btu/ft2/hr) UVB @ 50° C, 7x24
hr cycles
MIL-STD-810G Method 505.4
Agency approvals
iX104C5 User’s Handbook
109
