Chapter 1. Getting Started
Right side view
USB ports
Microphone
connector
LAN connector
Power
connector
Headphone
connector
9-pin serial
connector
(or optional External monitor)
The connectors on the bottom of the computer are located behind the outer doors.
Power connector
USB 2.0 ports
Headphone connector
Microphone connector
LAN connector
External monitor connector
(Optional) 9-pin serial port
iX104C5 User’s Handbook
For the AC adapter or optional auto adapter. (See “Optional accessories” on
page 16.)
For Universal Serial Bus devices (compliant with USB Standard Revision 2.0).
Note: The optional Office and Vehicle Docks include additional USB ports. See
“Optional accessories” on page 16.
For stereo headphones or speakers.
For an external microphone.
For connecting a standard RJ-45 connector to the tablet’s internal local area
network (LAN) card
For an external monitor or projection panel.
For connecting terminals or other devices that use the RS-232, RS-422, or RS-485
data transfer standard.
23
