Xtreme Power Conversion Corporaon
P91, TX91, TX91L, TXVR Service Manual
Page 5
Uninterrupble Power Supply
*Depending on load level.
MODEL NUMBER
TX91-3.8K TX91-5K TX91-6K TX91-10K
CAPACITY Power rang 3.8kVA (3.8kW) 5kVA (5kW) 6kVA (6kW) 10kVA (10kW)
INPUT
Voltage (nominal) 208VAC (200VAC, 220VAC, 230VAC, 240VAC oponal)
Voltage range 110-300VAC
Frequency 46–64Hz auto-sensing
OUTPUT
Voltage 240/120VAC or 230/115VAC
Voltage regulaon ± 1%
Frequency 50/60Hz ± 0.1Hz
Overload capacity 200% for 1 min 150% for 1 min 130% for 1 min
Eciency Up to 97% ECO mode, 91% online mode
BATTERY/CHARGER
Baery type Sealed, maintenance-free lead acid
Baery quanty and size
(standard / XR models)
(20) 12V 9AH / (20) 12V 580W
Charger voltage/current 273VDC / 1A-4A (selectable)
PHYSICAL
Input/output Terminal blocks or oponal PDU
Dimensions (W x D x H) 9.9 x 23.3 x 32.4 in
Weight 272 lbs 275 lbs 278 lbs 307 lbs
OPTIONAL
Baery quanty and size BP20-(20) 12V 9AH; BP40-(40) 12V 9AH; BP60-(60) 12V 9AH
BATTERY PACKS Dimensions (W x D x H) 9.9 x 23.3 x 32.4 in
Weight BP20 - 190lbs; BP40 - 320 lbs; BP60 - 450 lbs
OPTIONAL PDU
Input connecon Terminal blocks or 6 , L6–30P* Terminal blocks
120V receptacle opons 5–15/20R
240V receptacle opons L6–30R, L6–20R, 6–15/20R, C19
ENVIRONMENT
Temperature 32–104°F (0–40°C)
Audible noise < 50dBA
Altude 11,500  above sea level
APPROVALS UL1778, cUL, FCC Class A, RoHS
WARRANTY 3 years electronics, 3 years baery warranty (USA and Canada)
COMMUNICATIONS INTERFACE RS-232, EPO, intelligent slot for oponal cards (Web/SNMP, Relay/dry contact, Modbus)
INCLUDED IN BOX User manual, RS-232 communicaon cable, ViewPower Soware CD
AVAILABLE OPTIONS 5 year extended warranty, output PDU, input L6–30P cord (for 3.8kVA, 5kVA & 6kVA)
