X16D1H – User Manual
User can right click on the screen to bring up further motion detection options, as
detailed below:
Item
Description
CH01 – CH32
Select channel to setup motion detection
Mask Mouse Selection
Switch between select/deselect for the cursor-dragging
function (i.e. allows the user to draw out a grid on the screen
using the mouse)
Detect All Area
Selects the entire screen as detection area.
Mask All Area
Deselects the entire screen as a detection area.
Apply to All
Apply the current settings to all available channels
Exit
Exit and save settings (return to motion detection menu)
Close
Close the pop-up window
Please see section ‘Video Loss’ (Event setup – page 25) on further details and
Receiver Setup.
