Location of Depth Sensor (continued)
To assist with consistent horizontal orientation, the EXO2 sonde has
an indentation at the top of the sonde for a marker or positioning
pin.
e sonde should be installed with at least 1 cm of water above the
intake ports.
If a conductivity sensor is installed, the depth will be compensated
automatically for changes in the density of water as temperature
and salinity change.
Depth Configuration
EXO sondes must be ordered with a specic depth option: 0-10 m,
0-100 m, 0-250 m, or no depth. Once the depth selection is made,
the sonde’s depth sensor cannot be changed.
