Xylem EXO Series User Manual

pg | 7
2.9
1.2
Universal Sensor Ports
Wiper/Sensor Port
Pressure Transducer
Openings
EXO2 Sonde
Overview
e EXO2 sonde is a multiparameter instrument that collects water quality data. e sonde collects the
data with up to six user-replaceable sensors and an integral pressure transducer. Each sensor measures its
parameter via a variety of electrochemical, optical, or physical detection methods. Each port accepts any EXO
sensor and automatically recognizes the type of sensor. Depending on user-dened settings, the EXO2 will
collect data and store it onboard the sonde, transfer the data to a data collection platform (DCP), or relay it
to a user’s PC or EXO Handheld via cable, USB connection, or Bluetooth connection.
In addition to six standard sensor ports, the EXO2 also has a bulkhead port for a central wiper (or an
additional sensor) and an auxiliary port on top of the sonde. is auxiliary port will allow the user to connect
the EXO2 to other EXO sondes.
Users communicate with the sonde via a eld cable to an
EXO Handheld, Bluetooth® wireless connection to a PC or
EXO Handheld, or a USB connection (via communications
adapter) to a PC.
Specifications
Operating
Environment
Depth Rating
Medium
250 meters, 820 feet
Water
Material
Xenoy, Lexan, bronze,
titanium, copper-nickel
alloy, 316 stainless steel
Internal Logging
Memory Capacity
512 MB
Software
Kor Interface Software
Communications
Sonde
Adapters
Bluetooth, Field Cable,
USB, RS-485;
USB, SDI -12/RS -232
Power
External
Internal
9-16 VDC
4 D - size batteries
Temperature
Operating
Storage
-5 to
+
50°C
-20 to
+
80°C
Battery Life
90 days typically
(see pg 80)
Dimensions
Diameter
Length
Weight
7.62 cm, 3.00 in
71.1 cm, 28.00 in
2.65 kg, 5.83 lb
