Maximum supply ratings for UL- compliance
The table describes the drivers suitable for a circuit capable of delivering specified
maximum specified short-circuit Amperes symmetrical with the specified maximum supply
voltage.
Table 3: Drive ratings
Voltage (V) Ratings kW (HP) Maximum supply voltage V
rms
(AC)
Maximum supply short-circuit
current kA
rms
(AC)
230 0.37 – 18.5 (0.5 – 25.0) 240 5
22.0 – 90.0 (30.0 – 120.0) 10
400/460 0.75 – 37.0 (1.0 – 50.0) 500/600 5
45.0 – 132.0 (60.0 – 175.0) 10
160.0 (210.0) 18
Output power and current ratings
IP66
Table 4: 200 – 240 V (+ / -10%) 3–phase input, 3–phase output
kW HP Frame Size Nominal
Input Current
(A)
Fuse/MCB,
type B) (A)
Supply cable
(mm
2
)
Nominal
Output
Current (A)
150% Output
Current 60
seconds (A)
SUBCAB
®
cable (mm
2
)
4.0 5.0 3 17.3 32 6.0 18.0 19.80 2.5
Table 5: 380 – 480 V (+ / -10%) 3–phase input, 3–phase output
kW HP Frame Size Nominal
Input Current
(A)
Fuse/MCB,
type B) (A)
Supply cable
(mm
2
)
Nominal
Output
Current (A)
150% Output
Current 60
seconds (A)
SUBCAB
®
cable (mm
2
)
4.0 5.0 2 10.8 16 2.5 9.5 10.45 1.5
5.5 7.5 3 13.3 20 2.5 14.0 15.40 2.5
7.5 10.0 3 18.5 20 4.0 18.0 19.80 2.5
IP55
Table 6: 200 – 240 V (+ / -10%) 3–phase input, 3–phase output
kW HP Frame Size Nominal
Input Current
(A)
Fuse/MCB,
type B) (A)
Supply cable
(mm
2
)
Nominal
Output
Current (A)
150% Output
Current 60
seconds (A)
SUBCAB
®
cable (mm
2
)
5.5 7.5 4 25.0 40 6.0 24.0 26.40 4.0
7.5 10.0 4 46.6 50 10.0 39.0 42.9 6.0
15.0 20.0 5 69.6 80 25.0 61.0 67.1 16.0
22.0 30.0 6 92.3 100 35.0 90.0 99.0 25.0
Technical Reference
18 SRC 311 - SmartRun
™
User guide
