Installation Notes
Front Panel Light Activity Meaning
Ethernet A, B, or C LED ON Terminal server detects network
activity on Ethernet segment to which it
is attached..
CARD LED ON Unit is loading from a Memory card
(light ON for approximately 15 seconds).
☞ The Terminal Server 720 is
accessing the Memory card. Do
not remove the card while the
CARD light is ON.
RUN and Ethernet (A, B, or C) LEDs blink
simultaneously
Software load in progress.
Port lights go ON, sequentially from right (Port 8
status light) to left (Port 1 status light). Then,
lights go OFF from left to right.
Unit has finished loading the software
image, and is decompressing it.
RUN LED flashes slowly
Ethernet (A, B, or C) LED flashes when Ethernet
packets are received
Software loading has completed.
Terminal server is in normal operating
state.
If the LEDs do not behave as indicated, refer to the Appendix D.
0021 2-19
