Configuration Menu
Display Unit Configuration Menu - Choice X.
If you select choice X of the Display Unit Configuration Menu you will be returned to the
Terminal Server Configuration Menu (Figure C-1).
C.3.2 Option 2 - Modify Unit Configuration
To select this option, answer 2 to the "Enter menu selection" prompt of the Terminal Server
Configuration Menu. The menu display a Display Unit Configuration Menu, which is shown
in Figure C-5:
Modify Unit Configuration Menu
1. Load/dump configuration #1 (Enabled)
2. Load/dump configuration #2 (Disabled)
3. Load/dump configuration #3 (Disabled)
M. Miscellaneous unit configuration
D. Set unit configuration to defaults
X. Exit to main menu
Enter menu selection [X]:
Figure C-5. The Modify Unit Configuration Menu.
Modify Unit Configuration Menu - Choices 1, 2, and 3.
If you select choices 1, 2, or 3 of the Modify Unit Configuration Menu, the menu prompts one of
the following (depending on which number load/dump configuration you choose to modify):
Initialize load/dump configuration #1 to defaults (Y,N) [N]?
Initialize load/dump configuration #2 to defaults (Y,N) [N]?
Initialize load/dump configuration #3 to defaults (Y,N) [N]?
Valid answers to this prompt are Y (Yes) and N (No).
• If you answer ‘Y’, the unit returns all configuration options to their factory default values,
which are (Initialization Configuration 1 only; Configurations 2 and 3 are disabled):
Parameter load method: CARD, XMOP, MOP, BOOTP, RARP
Image load method: CARD, XMOP, MOP, BOOTP, RARP
Dump Method: XMOP, MOP, BOOTP, RARP
CARD/XMOP/MOP load filename: XPCSRV20
Default unit IP address: 0.0.0.0
Directed TFTP values 0.0.0.0 or N/A
Network Interface Segment A
C-68 0021
