I/O and Cabling Considerations
Table 3-3. Telco 36-Pin Pinout
Telco Signal Telco Signal
Pin Name Pin Name
Port 1 or 9: 1 XMTn 19 XMTn GND
2 RCVn 20 RCVn GND
Port 2 or 10: 3 XMTn 21 XMTn GND
4 RCVn 22 RCVn GND
Port 3 or 11 5 XMTn 23 XMTn GND
6 RCVn 24 RCVn GND
Port 4 or 12: 7 XMTn 25 XMTn GND
8 RCVn 26 RCVn GND
Port 5 or 13: 9 XMTn 27 XMTn GND
10 RCVn 28 RCVn GND
Port 6 or 14: 11 XMTn 29 XMTn GND
12 RCVn 30 RCVn GND
Port 7 or 15: 13 XMTn 31 XMTn GND
14 RCVn 32 RCVn GND
Port 8 or 16: 15 XMTn 33 XMTn GND
16 RCVn 34 RCVn GND
Note 1: Pins 17, 18, 35 and 36 are not used.
Note 2: The signal definitions are:
Signal Definition Type
XMTn Transmit Output (From server to terminal)
RCVn Receive Input (From terminal to server)
GND Logic Ground Common
where n is the port number.
3.3.11 DECconnect Style Modular Splitters
Eight-port and 24-port DECconnect style modular splitters with type MMJ connectors are
available. The splitters are similar to that shown in Figure 3-15. The 8-port splitter requires 1
DECconnect adaptor extension; the 24-port splitter requires 3 DECconnect adaptor extensions.
0021 3-41
