Technical Specifications
Item Description
Memory Base 2 MB DRAM, expandable to 4 MB with two 1 MB
SIMM memory modules.
Environment 10% to 90% humidity, noncondensing, 0° - 45° C
(32° - 113° F)
Power
Model 720 Processor Module:
Typical: +5Vdc - 1.5A
+12 Vdc - 0.0A
-12 Vdc - 0.0A
7W, 23.34 BTU/Hr
Model 721 I/O Module:
Typical: +5Vdc - 1.1A
+12 Vdc - 0.4A
-12 Vdc - 0.4A
15.1W, 50.3 BTU/Hr
Model 723 I/O Module:
Typical: +5Vdc - 1.3A
+12 Vdc - 0.6A
-12 Vdc - 0.6A
20.9W, 69.7 BTU/Hr
Model 724 I/O Module:
Typical: +5Vdc - 1.4A
+12 Vdc - 1.5A
-12 Vdc - 0.6A
29.1W, 72.9 BTU/Hr
Software Xyplex TCP/IP-LAT Software, V4.3 or later
Ethernet Interface Ethernet/IEEE 802.3 Connection provided by Network
9000 Chassis
A-55
