12
Supplied Accessories and Options
Supplied Accessories
• Rechargeable Li-Ion Battery Pack (7.4V, 1,750mAh) SBR-28LI
• AC adapter SAD-20
*
• Rapid Charger SBH-22
• Antenna SRA-15
• Belt Clip SHB-18
• Operating Manual (this manual)
• SBR-28LI Manual
If any item is missing, contact the dealer from which the transceiver was
purchased.
Available Options
• Rechargeable Li-Ion Battery Pack (7.4V, 1,750mAh) SBR-28LI
• AC adapter SAD-20
*
• Rapid Charger SBH-22
• VOX Earpiece Microphone SSM-512B
• Antenna SRA-15
• Speaker Microphone SSM-16B
• Programming Cable SCU-35
• Clone Cable SCU-36
• Belt Clip SHB-18
*
: Depending on the transceiver version.
Charging the Battery Pack
Charging the Battery Pack using the Rapid Charger (SBH-22)
Using the supplied SAD-20 AC Adapter and the supplied Rapid Charger, it
takes about 3.5 hours
*
to charge the SBR-28LI battery pack fully.
*
(Charging time may be increased, depending on the battery condition.)
1. Turn the transceiver OFF to install the battery
pack.
2. Referring to the figure at the right, connect the
battery charger plugs.
When the battery is being charged, the rapid
charger indicator lights red.
3. When charging is completed, the rapid charger
cradle indicator will light green.
AC Adapter
SAD-20
Rapid Charger
SBH-22
z
If the rapid charger indicator blinks red and the battery pack is not charged
after a lapse of 10 or more hours, stop charging the battery pack immediately.
The battery pack is presumed to be at the end of its service life, or defective.
In this case, replace the battery pack with a new one.
z
Charge the battery pack within the temperature range from +5 °C to +35 °C
(+41 °F to +95 °F).
To Next Page
