31
● Receiver
Circuit Type : Direct-conversion
Sensitivity : 0.2 μV for 12 dB SINAD (140 - 150 MHz, NFM)
0.2 μV for 12 dB SINAD (420 - 470 MHz, NFM)
Selectivity (-6 dB/-60 dB) : FM, NFM ±25 kHz / 12.5 kHz
AF Output : 800 mW (16 Ω for THD 10 % 7.4 V DC) internal
speaker
800 mW (16 Ω for THD 10 % 7.4 V DC)
external speaker
Specifications are subject to change without notice, and are guaranteed within the 144 MHz
and 430 MHz amateur bands only. Frequency ranges will vary according to transceiver
version; check with your dealer.
Symbols placed on the equipment
Direct current
