YAKO ES2 Series User Manual

Chapter 1: Selection of Servo System ES2 Series Servo User Manual Lite V1.0
2
Chapter 1: Selection of Servo System
1.1 Drive specifications
Table 1-1 ES2 series servo drive basic specifications
Basic spec
Drive model ES2-04B ES2-10B ES2-15B ES2-30B
Continuous output current Arms 2.8 5.5 7.6 11.6
Maximum output current Arms 10 17 17 28
Power supply input 220VAC
Main power
single/3 phase, AC200～230V, 50/60HZ
Control power Single phase, AC200~230V, 50/60HZ
Working environment
Temperature
Working：0℃～50℃
Storage：-20℃～85℃
Humidity
Below 0～90% RH（No condensation）
Working altitude Under altitude 1000m
Vibration/strike <1G
IP Grade /
Pollution level
IP20/ Pollution level 2
Control method IGBT PWM space vector control
Encoder 2500-line incremental
IO port
IO signal
Input
8（common）
Output
5（common）
Pulse signal
Input
2（Low speed pulse ）
Output
4（3 frequency output, 1 open collector output）
Communication
USB Connect with PC
Panel operator LED display
Regeneration function
Built-in braking resistor for 750W and above
models
Protection function
Overcurrent, overload, overvoltage, low voltage,
over speed, overheat, encoder error,
communication error, position deviation, etc.
Control mode Position control; speed control; torque control;
Function spec
Position control mode
Position command format
PULSE/DIR;
A, B phase orthogonal pulse;
Position input circuit Differential; open collector
Maximum input frequency
Differential 2Mpps
Open collector 2Mpps
Smoothing filter
Smoothing the position command to make the
motor run smoother and more stable
Electronic gear Provide 2 sets of electronic gear ratio
Vibration suppression filter
Effectively suppress external signal interference
and system resonance frequency to ensure stable
operation of equipment
