Chapter 1: Selection of Servo System ES2 Series Servo User Manual Lite V1.0
3
1.2 Servo motors and drives model description
Drive model description
ES2 – 04 B F I - XX
AC servo series
ES2YAKO ES2 series AC servo drive
Power
04: 400W 10: 1KW
15: 1.5KW 30: 3KW
Voltage level
B220V
Product type F: General
Installation methods I: Flange installation
Customized model xx: Customized design number
Servo motor type description
ASM D 0810 30 B - U 1 1 1 - XX
Series YAKO ES2 series AC servo motor
Feature D : Small inertia J: Large inertia H: High inertia
Flange 04:40mm 06: 60mm 08: 80mm 09:90mm 10:100mm
11: 110mm 13: 130mm
Power 04: 400W 10: 1KW 15: 1.5KW 30: 3KW
Rated speed(rpm) 10: 1000rpm 15: 1500 rpm 20: 2000 rpm 30: 3000 rpm
Voltage level
B200V
Encoder type U: 2500-line incremental
Shaft connection
type
1: Plain
2: Solid, with key
3: Solid, with key and threaded hole
4: Solid, with threaded hole
Brake, oil seal 1: none 2: oil seal 3: brake 4: oil seal + brake
Design number
1Ver. 1
Customized model xx: Customized design number
