Chapter 2: Product Installation and Dimensions
ES2 Series Servo User Manual Lite V1.0
7
Chapter 2: Product Insta
llation and Dimensions
2.1 Serv
o drive dimensions
Frame B: E
S2-04B, ES2
-08B,ES2-10B
Frame C: ,ES2
-15B, ES2
-30B
Table
2-1 Driver Dimensions
Model
L(mm)
H(
mm)
D(mm)
L1(
mm)
H1(mm)
D1(mm)
Screw hole
Frame C
90
160
183
80
150
75
4-M4
Frame B
58
160
177
48
150
75
2.2 Serv
o drive insta
llation
Figure 2-1 Servo d
rive installat
ion
7
