Chapter 1: Selection of Servo System ES2 Series Servo User Manual Lite V1.0
5
1.4 Matching motor number
Table 1-3 Motor number quick reference table
Motor
series
Rated
voltage
Servo motor model Motor number
ASM□-□□-□□□□□-***** (P01.00)
ASM 220V
ASMJ-06-0230B-U*** 6
ASMJ-06-0430B-U*** 7
ASMD-06-0630B-U***-M 13
ASMJ-08-0830B-U*** 8
ASMJ-09-0830B-U*** 12
ASMJ-08-1025B-U*** 101
ASMJ-09-1025B-U*** 115
ASMJ-11-1830B-U*** 108
ASMJ-11-1230B-U*** 112
ASMJ-11-1530B-U*** 103
ASMJ-13-1025B-U*** 104
ASMJ-13-1525B-U*** 105
ASMJ-13-2025B-U*** 109
ASMJ-13-2625B-U*** 110
ASMH-13-1010B-U*** 106
ASMH-13-1515B-U*** 107
ASMH-13-2315B-U*** 117
1.5 Auxiliary cable
Power cable naming rule:
P1 ES2 - 03 P08 M
Wire type P1: normal plug P2: Aviation plug
Drive series ES2 series drives
Cable length 03: 3 meter 05: 5 meter 10: 10 meter
Power P08:800W P15: 1.5KW P30: 3KW
Installation methods F: Fixed M: Movable
