132 Chapter 13—Onboard Effects
03D—Owner’s Manual
AUTOPAN
TREMELO
HQ.PITCH (Effect 2 only)
1. L<->R, L-->R, L<--R, Turn L, Turn R
Parameter Range Description
FREQ. 0.05–40.00 Hz Modulation speed.
DEPTH 0–100% Modulation depth.
DIR.
1
Select the direction in which the sound will move.
LSF F 21 Hz–1.0 kHz Frequency of the low shelving filter.
LSF G –12 to +12 dB Gain of the low shelving filter.
EQ F 99 Hz–8.0 kHz Frequency of the parametric equalizer.
EQ G –12 to +12 dB Gain of the parametric equalizer.
WAVE SINE, TRI Modulation waveform. SINE: sine wave, TRI: triangle wave
HSF F 500 Hz–16 kHz Frequency of the high shelving filter.
HSF G –12 to +12 dB Gain of the high shelving filter.
Parameter Range Description
FREQ. 0.05–40.00 Hz Modulation speed.
DEPTH 0–100% Modulation depth.
LSF F 21 Hz–1.0 kHz Frequency of the low shelving filter.
LSF G –12 to +12 dB Gain of the low shelving filter.
EQ F 99 Hz–8.0 kHz Frequency of the parametric equalizer.
EQ G –12 to +12 dB Gain of the parametric equalizer.
WAVE SINE, TRI Modulation waveform. SINE: sine wave, TRI: triangle wave
HSF F 500 Hz–16 kHz Frequency of the high shelving filter.
HSF G –12 to +12 dB Gain of the high shelving filter.
Parameter Range Description
PITCH –12 to +12 Amount of pitch change (semitones).
FINE –50 to +50 cent Fine adjustment (1 cent steps) to the pitch change.
DELAY 0.1–1000.0 ms Delay time of the pitch change.
FB.GAIN –99 to +99% Feedback amount.
MODE 1–10
Precision of the pitch change. Higher settings will produce
more accuracy, but longer delay time.
