A-S2000
39
(Side B)
BALANCE P.C.B.
• Semiconductor Location
D2019 F4
D2020 F4
D2021 G4
D2022 H4
D2023 H4
D2024 H4
D2027 E6
D2032 F5
D2033 F5
D2034 H5
D2035 C5
D2036 E5
D2037 H5
D2038 C5
D2039 E5
