Yamaha AS2000BL - Top View; Front View; Rear View; Internal View

8
A-S2000
A-S2000
■ INTERNAL VIEW
1 FRONT (14) P.C.B. (R, L models)
2 FUNCTION (3) P.C.B.
3 FRONT (13) P.C.B.
4 MAIN (2) P.C.B.
5 FUNCTION (2) P.C.B.
6 POWER TRANSFORMER
7 MAIN (3) P.C.B.
8 MAIN (1) P.C.B.
9 FRONT (12) P.C.B.
0 FRONT (11) P.C.B.
A FRONT (9) P.C.B.
B FRONT (2) P.C.B.
C FRONT (1) P.C.B.
D FRONT (3) P.C.B.
E FRONT (6) P.C.B.
F FRONT (5) P.C.B.
G FRONT (4) P.C.B.
H FRONT (7) P.C.B.
I FRONT (8) P.C.B.
J BALANCE P.C.B.
K FUNCTION (1) P.C.B.
L FRONT (10) P.C.B.
23 5 7 96
GFE
0
A
J K L
I
H
B
C D
14 8
Top View
Front View
Rear View
