■ InsEF (Insertion Effect)
Shows the on/off status of the Insertion Effects. If
“on” is displayed, this means that the Part’s signal is
being sent to the Insertion Effect Unit.
Insertion Effect switches for each Part are set in the
EFF Part screen (Page 127).
Part Receive Switch
Each Part can be set to receive Control Change and
Program Change messages. The following four screens
are available.
RCV Sw1 (Receive Switch 1)
RCV Sw2 (Receive Switch 2)
RCV Sw3 (Receive Switch 3)
RCV Sw4 (Receive Switch 4)
RCV Sw1 (Receive Switch 1)
When set to “on,” each Voice in each Part will receive
Control Settings (PB, MW, RB, AT) and Control
Change messages. The Controller parameters will vary
according to the Part selected.
This screen is not available for the A/D Input Part.
Parts 1 to 16
Drum Voice Part
Phrase Clip Part
Plug-in 1/2 Part
Multi Plug-in Part
❏ Settings:
PB (Pitch Bend Wheel): off, on
MW (Modulation Wheel): off, on
RB (Ribbon Controller): off, on
AT (Aftertouch): off, on
RCV Sw2 (Receive Switch 2)
When set to “on,” each Voice in each Part will receive
messages from Knob [1]/[2], plus Breath Controller,
Foot Controller and Control Change messages.
This screen is only available for Parts 1 to 16 (including
Drum Voice Parts) and the Phrase Clip Part.
Parts 1 to 16
Drum Voice Part
Phrase Clip Part
❏ Settings:
Knob1 (Knob [1]): off, on
Knob2 (Knob [2]): off, on
BC (Breath Controller): off, on
FC (Foot Controller): off, on
RCV Sw3 (Receive Switch 3)
When set to “on,” each Voice in each Part will receive
volume, pan, sustain pedal, foot switch and Control
Change messages.
Parts 1 to 16
Plug-in 1/2 Part
Multi Plug-in Part
Drum Voice Part
Phrase Clip Part
A/D Input Part
❏ Settings:
Vol (Volume): off, on
Pan: off, on
Sus (Sustain): off, on
FS (Foot Switch): off, on
RCV Sw4 (Receive Switch 4)
When set to “on,” each Voice in each Part will receive
Program Change and Control Change messages when
you change Performance Bank/Program.
❏ Settings:
BankSel (Bank Select): off, on
PgmChng (Program Change): off, on
CtrChng (Control Change): off, on
