13
DSP-A595a
No.5 SPEAKERS SET
The input is automatically discriminated by AC-3(DOLBY DIGITAL)>DTS Digital Surround>PCM Audio>analog.
There are the following 9 submenu items: The signal from the DSP block is normally in the effect off status for menu
items 1-4. For other menu items, the same signal as in 2. DSP THROUGH: YSS918 menu is output.
SUB MENU
CENTER SP
OUTPUTLFE/BASS
MAIN
LEVEL
MAIN SPREAR SP
REMOTE
CODE
1 MAIN:S 0DB 7A-8B LARGE LARGE SMALL 0dB SWFR MAIN L/R
2 MAIN:L 0DB 7A-8C LARGE LARGE LARGE 0dB SWFR MAIN L/R
3 MAIN:L -10 7A-8D LARGE LARGE LARGE -10dB SWFR MAIN L/R
4 B:MAIN C:N 7A-8E NONE LARGE LARGE 0dB MAIN MAIN L/R
5 LFE/B:MAIN 7A-8F LARGE LARGE LARGE 0dB MAIN LFE -> L/R
6 LFE/B:SWFR 7A-90 LARGE LARGE LARGE 0dB SWFR LFE -> SWFR
7 C:NONE 7A-91 NONE LARGE LARGE 0dB SWFR CENTER -> L/R
8 C:S REAR:S SMALL SMALL LARGE 0dB SWFR CENTER/REAR
9 FRONT MIX 7A-12 LARGE LARGE LARGE 0dB SWFR FRONT -> L/R
SUB MENU PURPOSE
1 MAIN:S 0DB Verification of the High and low pass filter response and gain in the bass redirection mode.
2 MAIN:L 0DB Reference of the sub menu No. 1 and 2.
3 MAIN:L -10 Verification of the effect in the main level function.
4 B:MAIN C:N Verification of the mixing circuit effect to the main channel.
5 LFE/B:MAIN Verification of the bass mix gain.
6 LFE/B:SWFR Verification of the LFE maximum output.
7 C:NONE Verification of the center mix gain.
8 C:S REAR:S Verification of the high and low pass filter response and gain in the bass redirection mode.
9 FRONT MIX Verification of the front mix gain.
LARGE: Mode in which speakers with high bass-sound playback capability (large unit) are used. Full frequency band
widths is output.
SMALL : Mode in which speakers with low bass-sound playback capability (small unit) are used. Frequncies below 90 Hz
are mixed with the channel specified by LFE/BASS.
NONE: Mode in which center speaker is not used. The center audio signal is reduced by 3 dB and mixed into MAIN L/R.
LFE/B: MAIN
: Mode in which subwoofer speaker is not used. The subwoofer audio signal is reduced by 4.5 dB and mixed into
MAIN L/R. But because of the phase difference, the MAIN L/R output is not simply summed.
The analog switches in each submenu are set as follows:
Purpose of the submenu as follows:
5 DVD/LD MAIN:S 0DB
5 DVD/LD B:MAIN C:N
5 DVD/LD C:NONE
5 DVD/LD MAIN:L 0DB
5 DVD/LD LFE/B:MAIN
5 DVD/LD C:S REAR:S
5 DVD/LD MAIN:L —10
5 DVD/LD LFE/B:SWFR
5 DVD/LD FRONT MIX
