9
DSP-A595a
● Selection by using the remote control unit
The remote control codes in the menu list (see right column
on page 6) correspond to the DSP program test and effect keys.
See the figure on the right.
3. OPERATION AND DISPLAY WHEN STARTING DIAGNOSIS FUNCTION
(1) Selection of diagnostic menu
The diagnostic menu and the sub-menu can be selected by using the front panel keys of the main unit or the remote
control unit.
(2) Other functions available while diagnosis function is active
Listed below are the other functions available while the diagnosis function is active.
• Selecting input source (Tape monitor/Ext. decoder)
• Adjusting effect level (Center, Rear, Subwoofer)
• Adjusting master volume
• Muting on/off
• Power on/off
(3) Diagnosis default status
When not otherwise specified, default settings and values in each menu are as follows:
• All “SPEAKERS” : LARGE
• ALL electronic VRs : 0dB
• DYNAMIC RANGE : MAX
• LFE LEVEL : 0dB (DOLBY DIGITAL, DTS)
• CENTER DELAY : 0ms
● Selection by using the front panel keys
The main menu can be changed cyclically by using the "TV SPORTS" and "DISCO" keys, and the submenu,
by using the "ROCK CONCERT" and "CONCERT HALL" keys. The "DISCO" or "CONCERT HALL" key will increase
the main or submenu number.
TV
SPORTS DISCO
ROCK
CONCERT
CONCERT
HALL
FRONT PANEL
Main menu
ForwardReverse
Sub menu
ForwardReverse
7A
D
S
P
To Next Page
