DSP-A595a
11 DVD/LD S-VER:Z08B
Main microprocessor check sum
DSP microprocessor check sum
Main microprocessor version
DSP microprocessor version
One suffix letter is for compatibility of communications between the main
and DSP microprocessors.
* Use microprocessors with the same suffix.
EXIT
✽1
Tuner Mode V2 (Port 96) 0*11*20*31*4
Tuner Mode V1 (Port 95) 0011
*1 AM:531–1611kHz/9kHz FM: 76.0–90.0MHz/100kHz (J model)
*2 AM:530–1710kHz/10kHz FM: 87.5–107.9MHz/200kHz (U, C models)
*3 AM:531–1611kHz/9kHz FM: 87.5–108.0MHz/50kHz (R, T, A, B, G, L models)
*4 AM: 530-1710kHz/10kHz FM:87.5-108.0 MHz/100kHz (R, T models)
✽2
bit 76543210
10000000
Always absent (0)
Always absent (0)
Tuner Mode V1 (✽1)
Tuner Mode V2 (✽1)
Always absent (0)
Always absent (0)
Model Type RDS (✽2)
Model Type DSP-A (✽2)
No.11 CPU VERSION/CHECK SUM/PORT INFO/EXIT DIAG
The check sum, version and port setting of main CPU/DSP CPU are displayed.
The signal is EFFECT OFF.
Operating the submenu will finish self-diagnosis, and ordinary operation mode will be restored.
The suffix letter ("B" in the following) of version indication is for compatibility of communications between the main and
DSP microprocessors.
Combining microprocessors with different suffixes will make normal operation impossible.
11 DVD/LD M-SM:XXXXX
11 DVD/LD S-SM:XXXXX
11 DVD/LD M-VER:Z04B
11 DVD/LD P:00000000
Model Type DSP-A(Port 83) 1 DSP-A595a 0 RX-V595aRDS 0 RX-V595a
HTR-5150
01 0
Model Type RDS(Port 70)
Hi=1, Low=0
Hi=1, Low=0
