123
P.C.B. DSP
C433 UB245100 C.CE.M.CHP 0.1uF 25V
* C434 UU128100 C.EL 100uF 10V
C901 VH053100 C.CE.TUBLR 0.1uF 50V
C902 VH053100 C.CE.TUBLR 0.1uF 50V
C903 VH053100 C.CE.TUBLR 0.1uF 50V
C904 VH053100 C.CE.TUBLR 0.1uF 50V
C905 VH053100 C.CE.TUBLR 0.1uF 50V
C906 VH053100 C.CE.TUBLR 0.1uF 50V
C907 UB245100 C.CE.M.CHP 0.1uF 25V
* C908 UU137100 C.EL 10uF 16V
C909 UB245100 C.CE.M.CHP 0.1uF 25V
C910 VH053100 C.CE.TUBLR 0.1uF 50V
C911 UB245100 C.CE.M.CHP 0.1uF 25V
* C912 UU167100 C.EL 10uF 50V
* C913 UU118330 C.EL 330uF 6.3V
C914 UB245100 C.CE.M.CHP 0.1uF 25V
C915 VJ901900 C.CE.M.CHP 100pF 50V
C916 UB245100 C.CE.M.CHP 0.1uF 25V
C917 VH053100 C.CE.TUBLR 0.1uF 50V
C918 VH053100 C.CE.TUBLR 0.1uF 50V
C921 VH053100 C.CE.TUBLR 0.1uF 50V
C922 VH053100 C.CE.TUBLR 0.1uF 50V
C923 VH053100 C.CE.TUBLR 0.1uF 50V
C924 VH053100 C.CE.TUBLR 0.1uF 50V
C925 VH053100 C.CE.TUBLR 0.1uF 50V
C926 VH053100 C.CE.TUBLR 0.1uF 50V
C927 VH053100 C.CE.TUBLR 0.1uF 50V
D1 VT332900 DIODE 1SS355
D2 VT332900 DIODE 1SS355
D3 VT332900 DIODE 1SS355
D4 VT332900 DIODE 1SS355
D5 VT332900 DIODE 1SS355
D6 VT332900 DIODE 1SS355
D7 VT332900 DIODE 1SS355
D8 VT332900 DIODE 1SS355
D9 VT332900 DIODE 1SS355
D10 VT332900 DIODE 1SS355
D11 VV220700 DIODE.SHOT RB501V-40
D12 VV220700 DIODE.SHOT RB501V-40
D13 VV220700 DIODE.SHOT RB501V-40
D14 VV220700 DIODE.SHOT RB501V-40
D15 VV220700 DIODE.SHOT RB501V-40
D16 VV220700 DIODE.SHOT RB501V-40
D17 VV220700 DIODE.SHOT RB501V-40
D18 VV220700 DIODE.SHOT RB501V-40
D19 VT332900 DIODE 1SS355
D20 VT707700 C.TRIM KV1851-TL
D901 VG438300 DIODE.ZENR MTZJ6.8B 6.8V
* D902 V2598200 LED SIR-505ST
G1 VR463400 TERM.GND D3.5 TP00385
G2 VR463400 TERM.GND D3.5 TP00385
G3 VR463400 TERM.GND D3.5 TP00385
* IC1 XW504A00 IC CPU,EPROM
* IC2 XW526A00 IC YSD917
* IC3 XW272A00 IC AK5383-VS
IC4 XP250A00 IC HD74HC00FPTR NAND
IC5 XU728A00 IC YSS908-F
IC6 XV304B00 IC YSS918D-F
* IC7 XV988A00 IC YSS910-S
* IC8 XV988A00 IC YSS910-S
* IC9 XV058A00 IC DF1704E
* IC10 XV057A00 IC PCM1704U
* IC11 XV057A00 IC PCM1704U
* IC12 XV058A00 IC DF1704E
* IC13 XV057A00 IC PCM1704U
* IC14 XV057A00 IC PCM1704U
* IC15 XV058A00 IC DF1704E
* IC16 XV057A00 IC PCM1704U
* IC17 XV057A00 IC PCM1704U
* IC18 XV058A00 IC DF1704E
* IC19 XV057A00 IC PCM1704U
* IC20 XV057A00 IC PCM1704U
* IC21 XV058A00 IC DF1704E
* IC22 XV057A00 IC PCM1704U
* IC23 XV057A00 IC PCM1704U
IC24 XT958A00 IC PM4007A
IC25 XV411A00 IC W24258S-70LE-EL10
IC33 XV077A00 IC MSM514260C-60JS
IC34 XV077A00 IC MSM514260C-60JS
IC35 XV077A00 IC MSM514260C-60JS
IC36 XP250A00 IC HD74HC00FPTR NAND
IC37 XP250A00 IC HD74HC00FPTR NAND
IC38 XF291A00 IC uPC4570G2
* IC39 XD598A00 IC TC74HCU04AFEL INV
* IC40 XD598A00 IC TC74HCU04AFEL INV
IC41 XS776A00 IC TC74HC126AF BUS BU
IC42 XQ248A00 IC TC74HC125AF BUS BU
IC43 XV493A00 IC HD74HC151FPEL
IC44 XV493A00 IC HD74HC151FPEL
IC45 XR038A00 IC NJM2904M OP AMP
IC46 XE518A00 IC uPC4574G2
IC47 XF291A00 IC uPC4570G2
IC48 XF291A00 IC uPC4570G2
IC49 XF291A00 IC uPC4570G2
IC50 XF291A00 IC uPC4570G2
IC51 XF291A00 IC uPC4570G2
IC52 XF291A00 IC uPC4570G2
IC53 XF291A00 IC uPC4570G2
IC54 XF291A00 IC uPC4570G2
IC55 XF291A00 IC uPC4570G2
IC56 XF291A00 IC uPC4570G2
IC57 XP250A00 IC HD74HC00FPTR NAND
* IC901 XY115A00 IC M66004MAFP-200C
* IC902 XY115A00 IC M66004MAFP-200C
L1 V2726500 COIL 68uH
L2 V2726500 COIL 68uH
