Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
124
P.C.B. DSP
L3 V2726500 COIL 68uH
L4 V2726500 COIL 68uH
L5 V2726500 COIL 68uH
L6 V2726500 COIL 68uH
L7 V2726500 COIL 68uH
L8 V2726500 COIL 68uH
L9 VT623200 FLTR.LC SBP-4930
PJ1 VZ726300 JACK.PIN 2P
PJ2 VZ726400 JACK.PIN 2P
Q1 iA103700 TR.CHP 2SA1037 Q,R,S
Q2 VV556400 TR 2SC2412K Q,R,S
Q3 VV556400 TR 2SC2412K Q,R,S
Q4 VV556400 TR 2SC2412K Q,R,S
Q5 VV556400 TR 2SC2412K Q,R,S
Q6 iA103700 TR.CHP 2SA1037 Q,R,S
Q7 iA103700 TR.CHP 2SA1037 Q,R,S
Q8 VV556400 TR 2SC2412K Q,R,S
Q901 iC241200 TR.CHP 2SC2412K Q,R,S
Q902 iC241200 TR.CHP 2SC2412K Q,R,S
Q903 iC241200 TR.CHP 2SC2412K Q,R,S
Q904 iC241200 TR.CHP 2SC2412K Q,R,S
Q905 iC241200 TR.CHP 2SC2412K Q,R,S
Q906 iC241200 TR.CHP 2SC2412K Q,R,S
Q907 iC241200 TR.CHP 2SC2412K Q,R,S
Q908 iC241200 TR.CHP 2SC2412K Q,R,S
Q909 iC241200 TR.CHP 2SC2412K Q,R,S
Q910 iC241200 TR.CHP 2SC2412K Q,R,S
R12 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R13 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R39 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R41 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R42 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R43 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R44 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R46 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R60 HV453100 R.CAR.FP 1Ω 1/4W
R66 HV454220 R.CAR.FP 22Ω 1/4W
R67 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R68 Vi191800 R.MTL.CHP 51Ω 1/10W
R69 Vi191800 R.MTL.CHP 51Ω 1/10W
R70 Vi191800 R.MTL.CHP 51Ω 1/10W
R71 Vi191800 R.MTL.CHP 51Ω 1/10W
R72 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R73 HV454220 R.CAR.FP 22Ω 1/4W
R82 HV453220 R.CAR.FP 2.2Ω 1/4W
R84 HV453100 R.CAR.FP 1Ω 1/4W
R85 Vi197400 R.MTL.CHP 10KΩ 1/10W
R86 Vi197400 R.MTL.CHP 10KΩ 1/10W
R91 HV453100 R.CAR.FP 1Ω 1/4W
R92 HV453100 R.CAR.FP 1Ω 1/4W
R95 HV454330 R.CAR.FP 33Ω 1/4W
R118 HV453100 R.CAR.FP 1Ω 1/4W
R119 HV453100 R.CAR.FP 1Ω 1/4W
R138 Vi195900 R.MTL.CHP 2.7KΩ 1/10W
R139 HV454220 R.CAR.FP 22Ω 1/4W
R141 Vi200000 R.MTL.CHP 100KΩ 1/10W
R142 Vi194900 R.MTL.CHP 1KΩ 1/10W
R143 Vi194900 R.MTL.CHP 1KΩ 1/10W
R144 Vi194900 R.MTL.CHP 1KΩ 1/10W
R145 Vi192500 R.MTL.CHP 100Ω 1/10W
R148 Vi195900 R.MTL.CHP 2.7KΩ 1/10W
R149 Vi200000 R.MTL.CHP 100KΩ 1/10W
R150 Vi194900 R.MTL.CHP 1KΩ 1/10W
R151 Vi194900 R.MTL.CHP 1KΩ 1/10W
R152 Vi194900 R.MTL.CHP 1KΩ 1/10W
R153 HV454220 R.CAR.FP 22Ω 1/4W
R154 Vi192500 R.MTL.CHP 100Ω 1/10W
R155 HV454150 R.CAR.FP 15Ω 1/4W
R156 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R157 Vi200000 R.MTL.CHP 100KΩ 1/10W
R158 Vi194900 R.MTL.CHP 1KΩ 1/10W
R159 Vi194900 R.MTL.CHP 1KΩ 1/10W
R160 Vi194900 R.MTL.CHP 1KΩ 1/10W
R161 HV454220 R.CAR.FP 22Ω 1/4W
R162 Vi192500 R.MTL.CHP 100Ω 1/10W
R163 Vi196400 R.MTL.CHP 3.9KΩ 1/10W
R164 Vi200000 R.MTL.CHP 100KΩ 1/10W
R165 HV454220 R.CAR.FP 22Ω 1/4W
R167 HV454150 R.CAR.FP 15Ω 1/4W
R168 Vi194900 R.MTL.CHP 1KΩ 1/10W
R169 Vi194900 R.MTL.CHP 1KΩ 1/10W
R170 Vi194900 R.MTL.CHP 1KΩ 1/10W
R171 Vi192500 R.MTL.CHP 100Ω 1/10W
R172 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R173 Vi200000 R.MTL.CHP 100KΩ 1/10W
R174 Vi194900 R.MTL.CHP 1KΩ 1/10W
R175 Vi194900 R.MTL.CHP 1KΩ 1/10W
R176 Vi194900 R.MTL.CHP 1KΩ 1/10W
R177 HV454220 R.CAR.FP 22Ω 1/4W
R178 Vi192500 R.MTL.CHP 100Ω 1/10W
R179 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R180 Vi200000 R.MTL.CHP 100KΩ 1/10W
R181 Vi194900 R.MTL.CHP 1KΩ 1/10W
R182 Vi194900 R.MTL.CHP 1KΩ 1/10W
R183 Vi194900 R.MTL.CHP 1KΩ 1/10W
R184 HV454220 R.CAR.FP 22Ω 1/4W
R185 Vi192500 R.MTL.CHP 100Ω 1/10W
R186 HV454150 R.CAR.FP 15Ω 1/4W
R187 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R188 HV454220 R.CAR.FP 22Ω 1/4W
R189 Vi200000 R.MTL.CHP 100KΩ 1/10W
R190 Vi194900 R.MTL.CHP 1KΩ 1/10W
R191 Vi194900 R.MTL.CHP 1KΩ 1/10W
R192 Vi194900 R.MTL.CHP 1KΩ 1/10W
R193 Vi192500 R.MTL.CHP 100Ω 1/10W
R194 HV454150 R.CAR.FP 15Ω 1/4W
