Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
125
P.C.B. DSP
R195 Vi196500 R.MTL.CHP 4.3KΩ 1/10W
R196 Vi200000 R.MTL.CHP 100KΩ 1/10W
R197 Vi194900 R.MTL.CHP 1KΩ 1/10W
R198 Vi194900 R.MTL.CHP 1KΩ 1/10W
R199 Vi194900 R.MTL.CHP 1KΩ 1/10W
R200 HV454220 R.CAR.FP 22Ω 1/4W
R201 Vi192500 R.MTL.CHP 100Ω 1/10W
R203 Vi196400 R.MTL.CHP 3.9KΩ 1/10W
R204 Vi200000 R.MTL.CHP 100KΩ 1/10W
R205 Vi194900 R.MTL.CHP 1KΩ 1/10W
R206 Vi194900 R.MTL.CHP 1KΩ 1/10W
R207 Vi194900 R.MTL.CHP 1KΩ 1/10W
R208 HV454220 R.CAR.FP 22Ω 1/4W
R209 Vi192500 R.MTL.CHP 100Ω 1/10W
R210 Vi196400 R.MTL.CHP 3.9KΩ 1/10W
R211 Vi200000 R.MTL.CHP 100KΩ 1/10W
R212 Vi194900 R.MTL.CHP 1KΩ 1/10W
R213 Vi194900 R.MTL.CHP 1KΩ 1/10W
R214 Vi194900 R.MTL.CHP 1KΩ 1/10W
R215 HV454220 R.CAR.FP 22Ω 1/4W
R216 Vi192500 R.MTL.CHP 100Ω 1/10W
R217 HV454150 R.CAR.FP 15Ω 1/4W
R218 HV454220 R.CAR.FP 22Ω 1/4W
R219 HV454220 R.CAR.FP 22Ω 1/4W
R238 HV453220 R.CAR.FP 2.2Ω 1/4W
R239 HV453220 R.CAR.FP 2.2Ω 1/4W
R240 HV453220 R.CAR.FP 2.2Ω 1/4W
R241 HV453220 R.CAR.FP 2.2Ω 1/4W
R242 HV453220 R.CAR.FP 2.2Ω 1/4W
R243 HV453220 R.CAR.FP 2.2Ω 1/4W
R244 HV453220 R.CAR.FP 2.2Ω 1/4W
R245 HV453220 R.CAR.FP 2.2Ω 1/4W
R246 HV453220 R.CAR.FP 2.2Ω 1/4W
R247 HV453220 R.CAR.FP 2.2Ω 1/4W
R250 Vi197400 R.MTL.CHP 10KΩ 1/10W
R251 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R252 Vi197400 R.MTL.CHP 10KΩ 1/10W
R253 Vi196600 R.MTL.CHP 4.7KΩ 1/10W
R264 VU224200 R.MTL.FLM 0.47Ω 1W
SW801 VZ075500 SW.SLIDE SL14-22AM5F(C)
SW901 VG392900 SW.TACT SKHVAA
SW902 VG392900 SW.TACT SKHVAA
U901 VR023400 L.DTCT SPS-424-1
* V901 V4472500 FL.DSPLY 32-BT-06G
XL1 V3625700 RSNR.CRYS 24.576MHz
XL2 VT928600 RSNR.CRYS 18.432MHz
* XL4 V4739000 RSNR.CE 16MHz
XL5 VZ156100 RESONATOR 60MHz
V3750100 PIN L=50
BB071360 SCR.TERM 8.3x13(UAC)
VP750600 SCR.TERM MEP1700
* V4329800 SUPRT FL
* V4329900 SHEET FL
