Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
126
P.C.B. TUNER (Lead Type)
V2518600 P.C.B. TUNER/TU-01(UC)
V2518800 P.C.B. TUNER/TU-01(A)
CB4 VQ961900 CN 16P
C1 VG288900 C.EL 100uF 25V
C3 VG275800 C.CE.TUBLR 8.2pF 50V
C4 VJ837200 C.EL 47uF 16V
C5 VF467300 C.CE.TUBLR 0.01uF 16V
C6 VJ837200 C.EL 47uF 16V
C7 VJ839100 C.EL 1uF 50V
C8 VF467300 C.CE.TUBLR 0.01uF 16V
C9 VF467300 C.CE.TUBLR 0.01uF 16V
C10 VF467300 C.CE.TUBLR 0.01uF 16V
C11 VF467000 C.CE.TUBLR 1000pF 50V
C12 VJ836900 C.EL 10uF 16V
C13 VJ836900 C.EL 10uF 16V
C14 FG212100 C.CE 100pF 50V
C15 VF467000 C.CE.TUBLR 1000pF 50V
C16 VF466700 C.CE.TUBLR 47pF 50V
C17 VJ837200 C.EL 47uF 16V
C19 VA760600 C.CE 10pF 50V
C20 VG288900 C.EL 100uF 25V
C21 VJ599000 C.CE.TUBLR 0.047uF 16V
C22 VG290700 C.EL 3.3uF 50V
C23 VF467300 C.CE.TUBLR 0.01uF 16V
C24 UM416470 C.EL 4.7uF 50V
C25 UM216330 C.EL 3.3uF 50V
C26 VJ836900 C.EL 10uF 16V
C27 VF467300 C.CE.TUBLR 0.01uF 16V
C28 VA760600 C.CE 10pF 50V
C29 VJ839100 C.EL 1uF 50V
C30 VJ839100 C.EL 1uF 50V
C31 VG288900 C.EL 100uF 25V
C32 VJ839000 C.EL 0.47uF 50V
C33 VJ839100 C.EL 1uF 50V
C34 UA654470 C.MYLAR 0.047uF 50V
C35 VG290700 C.EL 3.3uF 50V
C36 UA652270 C.MYLAR 270pF 50V(A)
C36 UA653100 C.MYLAR 1000pF 50V(UC)
C37 UA652270 C.MYLAR 270pF 50V(A)
C37 UA653100 C.MYLAR 1000pF 50V(UC)
C38 VF466900 C.CE.TUBLR 470pF 50V
C39 VG290900 C.EL 10uF 50V
C40 VG290700 C.EL 3.3uF 50V
C41 UA653390 C.MYLAR 3900pF 50V
C42 UM407220 C.EL 22uF 25V
C43 UA653390 C.MYLAR 3900pF 50V
C44 VG290700 C.EL 3.3uF 50V
C45 VJ837200 C.EL 47uF 16V
C46 VJ837200 C.EL 47uF 16V
C49 UA652120 C.MYLAR 120pF 50V(A)
C49 UA653220 C.MYLAR 2200pF 50V(UC)
C50 VJ599000 C.CE.TUBLR 0.047uF 16V
D1 VD631600 DIODE 1SS133,176,HSS104
D2 VD631600 DIODE 1SS133,176,HSS104
D3 VG437700 DIODE.ZENR MTZJ5.6B 5.6V
Fi1 GG000560 FLTR.CE SFE10.7MS3GHY-A
Fi2 GG000560 FLTR.CE
SFE10.7MS3GHY-A(UC
* Fi2 V4545200 FLTR.CE SFE10.7MJA1(A)
Fi3 VC219000 FLTR.CE SFZ450JL3
IC1 XB760A00 IC LA1266
IC2 XQ944A00 IC LC72131
IC3 iG158100 IC LA3401
L1 Vi546100 COIL 220uH
L2 Vi546100 COIL 220uH
L3 Vi546100 COIL 220uH
L4 Vi546100 COIL 220uH
PK1 V2716700 TUNER.PK ENV-172A4G1(A)
PK1 V2909100 TUNER.PK ENV-172C8G1R(UC)
PK2 VU333700 COIL.RF.AM 940536051A
Q1 iC053540 TR 2SC535 A,B,C
Q2 iC053540 TR 2SC535 A,B,C
Q3 VD678500 TR.DGT DTA114ES
Q4 iC174020 TR 2SC1740S R,S
Q5 VG722000 TR.DGT DTC144ES
Q6 iC1815C0 TR 2SC1815 Y
Q7 VD678500 TR.DGT DTA114ES
R56 HV454470 R.CAR.FP 47Ω 1/4W
* T1 V3725400 COIL.DT 10.7MHZ 104A
T2 VR895700 COIL.IF 450KHz
T3 VT486800 COIL XYA2(A)
T4 VQ138200 FLTR.LC 19KHz
T5 VQ138200 FLTR.LC 19KHz
TE1 VU477800 TERM.ANT AJ-2038-040
TP1 VT969000 PIN.TEST IRS-2049
TP2 VT969000 PIN.TEST IRS-2049
VR1 VJ694000 VR.TRIM B47KΩ
VR2 VJ694000 VR.TRIM B47KΩ
XL1 VY734600 RSNR.CRYS 7.2MHz
XL2 GG000750 RSNR.CE 18.95KHz
BB071360 SCR.TERM 8.3x13
VR282500 PLATE ANT.
