Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
127
P.C.B. TUNER (Lead Type & SMD)
* V2519300 P.C.B.CHP TUNER/TU-01(UC)
* V2519500 P.C.B.CHP TUNER/TU-01(A)
C1 VG287600 C.EL 100uF 25V
C3 UB050800 C.CE.M.CHP 8pF 50V
C4 UR837470 C.EL 47uF 16V
C5 UB044100 C.CE.M.CHP 0.01uF 50V
C6 UR837470 C.EL 47uF 16V
C7 UM416100 C.EL 1uF 50V
C8 UB044100 C.CE.M.CHP 0.01uF 50V
C9 UB044100 C.CE.M.CHP 0.01uF 50V
C10 UB044100 C.CE.M.CHP 0.01uF 50V
C11 UB013100 C.CE.M.CHP 1000pF 50V
C12 UM397100 C.EL 10uF 16V
C13 UM397100 C.EL 10uF 16V
C14 FG652100 C.CE 100pF 50V
C15 UB013100 C.CE.M.CHP 1000pF 50V
C16 UB051470 C.CE.M.CHP 47pF 50V
C17 UR837470 C.EL 47uF 16V
C19 V4006100 C.CE 10pF 50V
C20 VG287600 C.EL 100uF 25V
C21 UB044470 C.CE.M.CHP 0.047uF 50V
C22 VG290700 C.EL 3.3uF 50V
C23 UB044100 C.CE.M.CHP 0.01uF 50V
C24 UM406470 C.EL 4.7uF 50V
C25 UM416330 C.EL 3.3uF 50V
C26 UM397100 C.EL 10uF 16V
C27 UB044100 C.CE.M.CHP 0.01uF 50V
C28 VA760600 C.CE 10pF 50V
C29 UM416100 C.EL 1uF 50V
C30 UM416100 C.EL 1uF 50V
C31 VG287600 C.EL 100uF 25V
C32 UM415470 C.EL 0.47uF 50V
C33 UM416100 C.EL 1uF 50V
C34 UA954470 C.MYLAR 0.047uF 50V
C35 VG290700 C.EL 3.3uF 50V
C36 UA952270 C.MYLAR 270pF 50V(A)
C36 UA953100 C.MYLAR 1000pF 50V(UC)
C37 UA952270 C.MYLAR 270pF 50V(A)
C37 UA953100 C.MYLAR 1000pF 50V(U)
C38 UB012470 C.CE.M.CHP 470pF 50V
C39 VG287200 C.EL 10uF 50V
C40 VG290700 C.EL 3.3uF 50V
C41 UA953390 C.MYLAR 3900pF 50V
C42 UM397220 C.EL 22uF 25V
C43 UA953390 C.MYLAR 3900pF 50V
C44 VG290700 C.EL 3.3uF 50V
C45 UR837470 C.EL 47uF 16V
C46 UR837470 C.EL 47uF 16V
C47 UB012330 C.CE.M.CHP 330pF 50V
C48 UB012560 C.CE.M.CHP 560pF 50V
C49 UA952120 C.MYLAR 120pF 50V(A)
C49 UA953220 C.MYLAR 2200pF 50V(UC)
C50 UB044470 C.CE.M.CHP 0.047uF 50V
C51 UR837470 C.EL 47uF 16V
C52 UR837470 C.EL 47uF 16V
C53 UR837470 C.EL 47uF 16V
C54 VA761100 C.CE 27pF 50V
C55 VA761100 C.CE 27pF 50V
C56 UB044470 C.CE.M.CHP 0.047uF 50V
C57 UB012330 C.CE.M.CHP 330pF 50V
CB4 VQ961900 CN 16P
D1 VT332900 DIODE 1SS355
D2 VT332900 DIODE 1SS355
D3 VU172000 DIODE.ZENR UDZS5.6BTE-17 5.6V
Fi1 GG000560 FLTR.CE SFE10.7MS3GHY-A
Fi2 GG000560 FLTR.CE SFE10.7MS3GHY-A
Fi3 VC219000 FLTR.CE SFZ450JL3
IC1 XB760A00 IC LA1266
IC2 XQ944A00 IC LC72131
IC3 iG158100 IC LA3401
L1 VU889500 COIL 220uH
L2 VU889500 COIL 220uH
L3 VU889500 COIL 220uH
L4 VU889500 COIL 220uH
L5 VU889500 COIL 220uH
PK1 V2716700 TUNER.PK ENV-172A4G1(A)
PK1 V2909100 TUNER.PK ENV-172C8G1R(UC)
PK2 VU333700 COIL.RF.AM 940536051A
Q1 iC053540 TR 2SC535 A,B,C
Q2 iC053540 TR 2SC535 A,B,C
Q3 VD678500 TR.DGT DTA114ES
Q4 iC174020 TR 2SC1740S R,S
Q5 VG722000 TR.DGT DTC144ES
Q6 iC1815I0 TR 2SC1815 Y
Q7 VD678500 TR.DGT DTA114ES
R56 HV754470 R.CAR.FP 47Ω 1/4W
* T1 V3725400 COIL.DT 10.7MHZ 104A
T2 VR895700 COIL.IF 450KHz
T3 VT486800 COIL XYA2(A)
T4 VQ138200 FLTR.LC 19KHz
T5 VQ138200 FLTR.LC 19KHz
TE1 VU477800 TERM.ANT AJ-2038-040
TP1 VT969000 PIN.TEST IRS-2049
TP2 VT969000 PIN.TEST IRS-2049
VR1 VJ694000 VR.TRIM B47KΩ
VR2 VJ694000 VR.TRIM B47KΩ
XL1 VY734600 RSNR.CRYS 7.2MHz
XL2 GG000750 RSNR.CE 18.95KHz
XL3 V3930900 RSNR.CRYS 4.332MHz
BB071360 SCR.TERM 8.3x13
VR282500 PLATE ANT.
