The analog switch settings for each sub-menu are as shown in the table below.
Sub-menu
1 MAIN : SMALL 0dB
2 MAIN : LARGE -10
3 CENTER : NONE
4 LFE/BASS : MAIN
5 FRONT MIX : 5ch
6 CENTER : SMALL
7 REAR : SMALL
CENTER
LARGE
LARGE
NONE
LARGE
LARGE
SMALL
LARGE
REAR
LARGE
LARGE
LARGE
LARGE
LARGE
LARGE
SMALL
MAIN SP
SMALL
LARGE
LARGE
LARGE
LARGE
LARGE
LARGE
MAIN LVL
0dB
-10dB
0dB
0dB
0dB
0dB
0dB
LFE/BASS
SWFR
SWFR
SWFR
MAIN
SWFR
SWFR
SWFR
FRONT MIX
7ch
7ch
7ch
7ch
5ch
7ch
7ch
LARGE: Signals are output in all bandwidths.
SMALL: Only signals lower than 90Hz are mixed in the channel specified by LFE/BASS.
NONE: The center contents are distributed to the MAIN L/R channels after -3dB.
6. SPEAKERS SET
MAIN:SMALL 0dB
6. SPEAKERS SET
MAIN:LARGE -10
6. SPEAKERS SET
CENTER:NONE
6. SPEAKERS SET
LFE/BASS:MAIN
6. SPEAKERS SET
FRONT MIX:5ch
6. SPEAKERS SET
CENTER:SMALL
6. SPEAKERS SET
REAR:SMALL
Sub-menu
1 MAIN : SMALL 0dB
2 MAIN : LARGE -10
3 CENTER : NONE
4 LFE/BASS : MAIN
5 FRONT MIX : 5ch
6 CENTER : SMALL
7 REAR : SMALL
Application
Confirmation of high/low pass filter characteristic and gain when BASS REDIRECTION is used.
Confirmation of the effects of MAIN LEVEL function
Confirmation of gain of CENTER MIX (Only CENTER contents are output from MAIN L/R.)
Confirmation of gain of BASS MIX (Only LFE/BASS contents are output from MAIN L/R.)
Confirmation of gain of FRONT MIX (Only FRONT contents are output from MAIN L/R.)
Confirmation of high/low pass filter characteristic and gain when BASS REDIRECTION is used.
Confirmation of high/low pass filter characteristic and gain when BASS REDIRECTION is used.
[Remote Control Code: 7A—88 (PRG 1)] [Remote Control Code: 7A—89 (PRG 2)]
[Remote Control Code: 7A—8B (PRG 4)]
[Remote Control Code: 7A—8C (PRG 5)]
[Remote Control Code: 7A—8E (PRG 7)]
6. SPEAKERS SET
The input signal is automatically identified in the priority order of dts > DOLBY DIGITAL > PCM >
Analog. There are seven sub-menu items.
The signals output from the DSP are the same as 1. DSP THROUGH: DSP 0dB.
[Remote Control Code: 7A—8A (PRG 3)]
[Remote Control Code: 7A—8D (PRG 6)]
