Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
103
P.C.B. MAIN
* V5001000 P.C.B. MAIN(U)
* V5001100 P.C.B. MAIN(C)
* V5001200 P.C.B. MAIN(RT)
* V5001300 P.C.B. MAIN(A)
* V5001400 P.C.B. MAIN(BG)
CB452 VD004500 CN.BS.PIN 2P(C)
* CB501 V4807200 CN.BS.PIN 16P
* CB502 V4807300 CN.BS.PIN 18P
CB503 VD004500 CN.BS.PIN 2P
CB504 VD004500 CN.BS.PIN 2P
CB505 VD004500 CN.BS.PIN 2P
CB506 VD004500 CN.BS.PIN 2P
CB507 VD004500 CN.BS.PIN 2P
CB508 VD004500 CN.BS.PIN 2P
CB509 VD004500 CN.BS.PIN 2P
CB510 VD004500 CN.BS.PIN 2P
CB701 LA002400 TERM.WRAP 3P L-753B
CB702 VP206500 HOLDER.FUS EYF-52BC
CB703 VP206500 HOLDER.FUS EYF-52BC
CB704 LA002390 TERM.WRAP 2P
CB705 VP206500 HOLDER.FUS EYF-52BC
CB706 VP206500 HOLDER.FUS EYF-52BC
CB707 LA002390 TERM.WRAP 2P
CB708 VD004500 CN.BS.PIN 2P
CB709 VB858500 CN.BS.PIN 6P
* C451 UU149680 C.EL 6800uF 25V
* C452 UU149680 C.EL 6800uF 25V
* C453 UU13A100 C.EL 10000uF 16V
* C454 UU13A100 C.EL 10000uF 16V
* C455 UU13A100 C.EL 10000uF 16V
* C456 UU139680 C.EL 6800uF 16V
* C457 UU13A100 C.EL 10000uF 16V
C458 VR168300 C.MYLAR.ML ECQ-V1H104JL3
* C459 UU137470 C.EL 47uF 16V
* C460 UU166100 C.EL 1uF 50V
* C461 UU139100 C.EL 1000uF 16V
* C462 UU166100 C.EL 1uF 50V
* C463 UU139100 C.EL 1000uF 16V
* C464 UU137470 C.EL 47uF 16V
* C465 UU13A100 C.EL 10000uF 16V
* C466 UU166100 C.EL 1uF 50V
* C467 UU166100 C.EL 1uF 50V
* C468 UU137470 C.EL 47uF 16V
* C469 UU137470 C.EL 47uF 16V
* C470 UU137470 C.EL 47uF 16V
* C471 UU166100 C.EL 1uF 50V
* C472 UU166100 C.EL 1uF 50V
* C473 UU166100 C.EL 1uF 50V
C474 VH053100 C.CE.TUBLR 0.1uF 50V
C475 VH053100 C.CE.TUBLR 0.1uF 50V
C476 VH053100 C.CE.TUBLR 0.1uF 50V
C477 VH053100 C.CE.TUBLR 0.1uF 50V
C478 VH053100 C.CE.TUBLR 0.1uF 50V
* C501 UU167220 C.EL 22uF 50V
* C502 UU197470 C.EL 47uF 100V
* C503 UU167220 C.EL 22uF 50V
* C504 UU167220 C.EL 22uF 50V
C505 FU452100 C.MICA 100pF 500V
C506 FU452100 C.MICA 100pF 500V
C507 FU452100 C.MICA 100pF 500V
C508 FU452100 C.MICA 100pF 500V
C509 FU452100 C.MICA 100pF 500V
C510 FU452100 C.MICA 100pF 500V
C511 VR325300 C.MYLAR 0.047uF 100V
C512 UT454100 C.PP 0.01uF 100V
* C513 UU197100 C.EL 10uF 100V
C514 VR325300 C.MYLAR 0.047uF 100V
* C515 UU197100 C.EL 10uF 100V
C516 UT454100 C.PP 0.01uF 100V
C517 VR325300 C.MYLAR 0.047uF 100V
* C518 UU167100 C.EL 10uF 50V
C519 UT452100 C.PP 100pF 100V
* C520 UU197470 C.EL 47uF 100V
C521 UT453100 C.PP 1000pF 100V
* C522 UU167100 C.EL 10uF 50V
C523 UT452100 C.PP 100pF 100V
* C524 UU197470 C.EL 47uF 100V
C525 UT453100 C.PP 1000pF 100V
C526 FU451150 C.MICA 15pF 500V
C527 UT452100 C.PP 100pF 100V
* C528 UU128100 C.EL 100uF 10V
* C529 UU167220 C.EL 22uF 50V
C530 FU451150 C.MICA 15pF 500V
C531 UT452100 C.PP 100pF 100V
* C532 UU128100 C.EL 100uF 10V
* C533 UU167220 C.EL 22uF 50V
* C534 UU167220 C.EL 22uF 50V
* C535 UU197470 C.EL 47uF 100V
C536 FU452100 C.MICA 100pF 500V
C537 FU452100 C.MICA 100pF 500V
C538 FU452100 C.MICA 100pF 500V
C539 FU452100 C.MICA 100pF 500V
C540 FU452100 C.MICA 100pF 500V
C541 FU452100 C.MICA 100pF 500V
C542 VR325000 C.MYLAR 100pF 100V
* C543 UU167470 C.EL 47uF 50V
* C544 UU167470 C.EL 47uF 50V
C545 VR325000 C.MYLAR 100pF 100V
C546 VR325000 C.MYLAR 100pF 100V
* C547 UU167470 C.EL 47uF 50V
* C548 UU168100 C.EL 100uF 50V
* C549 UU167470 C.EL 47uF 50V
C550 VR325000 C.MYLAR 100pF 100V
C551 UT454100 C.PP 0.01uF 100V
C552 VR325300 C.MYLAR 0.047uF 100V
C553 VE326200 C.MYLAR.ML 0.15uF 50V
