Yamaha DSP-AX1/RX-V1 User Manual

DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
104
P.C.B. MAIN
C554 UT454100 C.PP 0.01uF 100V
C555 UT454100 C.PP 0.01uF 100V
C556 VR325300 C.MYLAR 0.047uF 100V
C557 VE326200 C.MYLAR.ML 0.15uF 50V
C558 UT454100 C.PP 0.01uF 100V
C559 VR325300 C.MYLAR 0.047uF 100V
C560 VE326200 C.MYLAR.ML 0.15uF 50V
C561 UA654220 C.MYLAR 0.022uF 50V
* C562 UU167470 C.EL 47uF 50V
* C563 UU167470 C.EL 47uF 50V
C564 UA654220 C.MYLAR 0.022uF 50V
* C565 UU197100 C.EL 10uF 100V
C566 VE324800 C.MYLAR.ML 0.01uF 50V
* C567 UU197100 C.EL 10uF 100V
* C568 UU197100 C.EL 10uF 100V
C569 VE324800 C.MYLAR.ML 0.01uF 50V
* C570 UU197100 C.EL 10uF 100V
C571 VE324800 C.MYLAR.ML 0.01uF 50V
C701 Vi862200 C.POLY 0.1uF 100V
C702 Vi862200 C.POLY 0.1uF 100V
C703 Vi862200 C.POLY 0.1uF 100V
C704 Vi862200 C.POLY 0.1uF 100V(C)
C705 Vi862200 C.POLY 0.1uF 100V(C)
C706 Vi862200 C.POLY 0.1uF 100V
C707 Vi862200 C.POLY 0.1uF 100V
C708 Vi862200 C.POLY 0.1uF 100V
* C709 UU159100 C.EL 1000uF 35V
* C710 UU166100 C.EL 1uF 50V
* C711 UU167100 C.EL 10uF 50V
* C712 UU177470 C.EL 47uF 63V
C713 VZ726000 C.EL 27000uF 71V
C714 VZ726000 C.EL 27000uF 71V
* C715 V5089400 C.EL 6800uF 45V
* C716 V5089400 C.EL 6800uF 45V
* C717 UU166470 C.EL 4.7uF 50V
* C718 UU168100 C.EL 100uF 50V
* C719 UU137100 C.EL 10uF 16V
* C720 UU168100 C.EL 100uF 50V
C728 FG244220 C.CE 0.022uF 50V(RTABG)
C728 UA654220 C.MYLAR 0.022uF 50V(UC)
C729 FG244220 C.CE 0.022uF 50V(RTABG)
C729 UA654220 C.MYLAR 0.022uF 50V(UC)
C732 FG244220 C.CE 0.022uF 50V(RTABG)
C732 UA654220 C.MYLAR 0.022uF 50V(UC)
C733 FG244220 C.CE 0.022uF 50V(RTABG)
C733 UA654220 C.MYLAR 0.022uF 50V(UC)
C740 FG244220 C.CE 0.022uF 50V(RTABG)
C740 UA654220 C.MYLAR 0.022uF 50V(UC)
C741 FG244220 C.CE 0.022uF 50V(RTABG)
C741 UA654220 C.MYLAR 0.022uF 50V(UC)
C742 FG244220 C.CE 0.022uF 50V(RTABG)
C742 UA654220 C.MYLAR 0.022uF 50V(UC)
C743 FG244220 C.CE 0.022uF 50V(RTABG)
C743 UA654220 C.MYLAR 0.022uF 50V(UC)
C744 FG244220 C.CE 0.022uF 50V(RTABG)
C744 UA654220 C.MYLAR 0.022uF 50V(UC)
C745 FG244220 C.CE 0.022uF 50V(RTABG)
C745 UA654220 C.MYLAR 0.022uF 50V(UC)
D451 VU391800 DIODE.SHOT AK04 WK
D453 VU647200 DIODE.SHOT RB441Q-40 T-77
D454 iF004600 DIODE 1SS133
D455 VU391800 DIODE.SHOT AK04 WK
D456 VU391800 DIODE.SHOT AK04 WK
D459 VG440800 DIODE.ZENR MTZJ15B 15V(RT)
D501 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D503 iF004600 DIODE 1SS133
D504 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D506 iF004600 DIODE 1SS133
D507 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D509 iF004600 DIODE 1SS133
D510 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D511 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D512 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D513 VC398400 DIODE MA185
D514 VC398400 DIODE MA185
D515 VC398400 DIODE MA185
D516 VC398400 DIODE MA185
D517 VC398400 DIODE MA185
D518 VC398400 DIODE MA185
D519 iF004600 DIODE 1SS133
D520 iF004600 DIODE 1SS133
D521 iF004600 DIODE 1SS133
D522 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D524 iF004600 DIODE 1SS133
D525 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D527 iF004600 DIODE 1SS133
D528 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D530 iF004600 DIODE 1SS133
D531 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D532 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D533 VG435100 DIODE.ZENR MTZJ2.0B 2.0V
D534 VN008700 DIODE 1SS270A
D535 VN008700 DIODE 1SS270A
D536 VN008700 DIODE 1SS270A
D537 VN008700 DIODE 1SS270A
D538 VC398400 DIODE MA185
D539 VC398400 DIODE MA185
D540 VC398400 DIODE MA185
D541 VC398400 DIODE MA185
D542 VC398400 DIODE MA185
D543 VC398400 DIODE MA185
Z D701 V2261600 DIODE.BRG RBV1306 13A600V(C)
Z D701 VZ755200 DIODE.BRG D15XB20 15A200V(URTABG)
Z D702 V2954200 DIODE.BRG D10XB20 10A200V(C)
Z D703 VN011300 DIODE.BRG D3SBA20 4A 200V
D704 VG442900 DIODE.ZENR MTZJ27B 27V
