DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
105
P.C.B. MAIN
D705 VG443500 DIODE.ZENR MTZJ30D 30V
D726 iF004600 DIODE 1SS133
Z F701 VS823100 FUSE 6.0A 125V(UC)
Z * F701 VT943300 FUSE TH 6.30A S(RTABG)
Z F702 VS823100 FUSE 6.0A 125V(UC)
Z * F702 VT943300 FUSE TH 6.30A S(RTABG)
G451 VR463400 TERM.GND D3.5 TP00385
G501 VR463400 TERM.GND D3.5 TP00385
HS701 VZ681300 HEAT.SINK PWR
Z IC451 XU814A00 IC PQ05RD11 +5V 1.0A
Z IC452 XJ602A00 IC NJM78M12FA
Z IC453 XD343A00 IC NJM79M12FA
Z IC454 XU814A00 IC PQ05RD11 +5V 1.0A
Z IC455 XK309A00 IC NJM7905FA -5V
Z IC456 XU814A00 IC PQ05RD11 +5V 1.0A
Z * IC457 XY045A00 IC PQ3RD13 3.3V 1.0A
L501 GD900470 COIL 1.5uH
L502 GD900470 COIL 1.5uH
L503 GD900470 COIL 1.5uH
L504 GD900470 COIL 1.5uH
L505 VC664100 COIL 0.95uH
L506 VC664100 COIL 0.95uH
L507 VC664100 COIL 0.95uH
L726 VU751000 COIL 1.5uH
Q501 VE198700 TR 2SA1145 O,Y
Q502 VE198800 TR 2SC2705 O,Y
Q503 VE198700 TR 2SA1145 O,Y
Q504 VE198800 TR 2SC2705 O,Y
Q505 VE198700 TR 2SA1145 O,Y
Q506 VE198800 TR 2SC2705 O,Y
Q507 VE198800 TR 2SC2705 O,Y
# Q508 VC398100 TR 2SC1846 S
Q509 VE198700 TR 2SA1145 O,Y
Q510 VE198800 TR 2SC2705 O,Y
# Q511 VC398100 TR 2SC1846 S
Q512 VE198700 TR 2SA1145 O,Y
Q513 VE198800 TR 2SC2705 O,Y
# Q514 VC398100 TR 2SC1846 S
Q515 VE198700 TR 2SA1145 O,Y
Z Q516A iX632610 TR 2SA1837 O,Y
Z Q516C iX632620 TR 2SC4793 O,Y
Z # Q517 V4863600 TR.PAIR 2SA1943/C5200 O,R
Z Q520A iX632610 TR 2SA1837 O,Y
Z Q520C iX632620 TR 2SC4793 O,Y
Z # Q521 V4863600 TR.PAIR 2SA1943/C5200 O,R
Z Q524A iX632610 TR 2SA1837 O,Y
Z Q524C iX632620 TR 2SC4793 O,Y
Z # Q525 V4863600 TR.PAIR 2SA1943/C5200 O,R
Q528 iC224030 TR 2SC2240 GR,BL
Q529 iC224030 TR 2SC2240 GR,BL
Q530 iC224030 TR 2SC2240 GR,BL
Q531 iA097000 TR 2SA970 GR,BL
Q532 iA097000 TR 2SA970 GR,BL
Q533 VD488500 TR.DGT DTC143XS
Q534 VD488500 TR.DGT DTC143XS
Q535 VE198700 TR 2SA1145 O,Y
Q536 iA097000 TR 2SA970 GR,BL
Q537 VE198800 TR 2SC2705 O,Y
Q538 iC1815C0 TR 2SC1815 Y
Q539 iC1815C0 TR 2SC1815 Y
Q540 iC1815C0 TR 2SC1815 Y
Q541 VE198700 TR 2SA1145 O,Y
Q542 iA097000 TR 2SA970 GR,BL
Q543 VE198800 TR 2SC2705 O,Y
Q544 iC1815C0 TR 2SC1815 Y
Q545 iC1815C0 TR 2SC1815 Y
Q546 iC1815C0 TR 2SC1815 Y
Q547 VE198700 TR 2SA1145 O,Y
Q548 VE198800 TR 2SC2705 O,Y
Q549 iC174020 TR 2SC1740S R,S
Q550 VD488500 TR.DGT DTC143XS
Q551 VE198800 TR 2SC2705 O,Y
# Q552 VC398100 TR 2SC1846 S
Q553 VE198700 TR 2SA1145 O,Y
Q554 VE198800 TR 2SC2705 O,Y
# Q555 VC398100 TR 2SC1846 S
Q556 VE198700 TR 2SA1145 O,Y
Q557 VE198800 TR 2SC2705 O,Y
# Q558 VC398100 TR 2SC1846 S
Q559 VE198700 TR 2SA1145 O,Y
Z # Q560 VC398100 TR 2SC1846 S
Z # Q561 VC398100 TR 2SC1846 S
Z Q562A iX632610 TR 2SA1837 O,Y
Z Q562C iX632620 TR 2SC4793 O,Y
Z # Q563 V4863600 TR.PAIR 2SA1943/C5200 O,R
Z # Q566 V4863600 TR.PAIR 2SA1943/C5200 O,R
Z Q567A iX632610 TR 2SA1837 O,Y
Z Q567C iX632620 TR 2SC4793 O,Y
Z # Q570 V4863600 TR.PAIR 2SA1943/C5200 O,R
Z Q571A iX632610 TR 2SA1837 O,Y
Z Q571C iX632620 TR 2SC4793 O,Y
Z Q574 VP872700 TR 2SC4488 S,T
# Q575A iX615750 TR 2SA1694 O,P,Y
# Q575C iX615760 TR 2SC4467 O,P,Y
Q576 iC224030 TR 2SC2240 GR,BL
Z Q578 VP872600 TR 2SA1708 S,T
Z Q579 VP872700 TR 2SC4488 S,T
# Q580A iX615750 TR 2SA1694 O,P,Y
# Q580C iX615760 TR 2SC4467 O,P,Y
Q581 iC224030 TR 2SC2240 GR,BL
Z Q583 VP872600 TR 2SA1708 S,T
Q584 iC224030 TR 2SC2240 GR,BL
Q585 iC224030 TR 2SC2240 GR,BL
Q586 iC224030 TR 2SC2240 GR,BL
Z Q701 VS548300 TR 2SB1375
Q702 iC1815C0 TR 2SC1815 Y
