DSP-AX1/RX-V1
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
107
P.C.B. MAIN & VIDEO
Z R637 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R640 VK188400 R.FUS 330Ω 1/4W
Z R641 HZ003780 R.MTL.PLAT 0.22Ω+0.22 5W
Z R643 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R646 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R649 VK188400 R.FUS 330Ω 1/4W
Z R650 HZ003780 R.MTL.PLAT 0.22Ω+0.22 5W
Z R652 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R655 VE009700 R.FUS 4.7Ω 1/4W
Z R659 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R661 VE009700 R.FUS 4.7Ω 1/4W
Z R664 VE009700 R.FUS 4.7Ω 1/4W
Z R668 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R670 VE009700 R.FUS 4.7Ω 1/4W
Z R676 HV453470 R.CAR.FP 4.7Ω 1/4W
Z R679 HV454100 R.CAR.FP 10Ω 1/4W
Z R680 HL314100 R.MTL.OXD 10Ω 1W
Z R681 HL314100 R.MTL.OXD 10Ω 1W
Z R683 HV454100 R.CAR.FP 10Ω 1/4W
Z R685 HL314100 R.MTL.OXD 10Ω 1W
Z R688 HL314100 R.MTL.OXD 10Ω 1W
Z R691 HL314100 R.MTL.OXD 10Ω 1W
R707 HV456820 R.CAR.FP 8.2KΩ 1/4W
Z R708 HV455100 R.CAR.FP 100Ω 1/4W
Z R709 HV453220 R.CAR.FP 2.2Ω 1/4W
Z R710 HL314330 R.MTL.OXD 33Ω 1W
Z R711 HV456330 R.CAR.FP 3.3KΩ 1/4W
Z R712 HV456470 R.CAR.FP 4.7KΩ 1/4W
Z R714 HL314100 R.MTL.OXD 10Ω 1W
Z R730 HV454100 R.CAR.FP 10Ω 1/4W
RY501 VK438300 RELAY DH24D2-OT/M2
RY502 VK438300 RELAY DH24D2-OT/M2
RY503 VK438300 RELAY DH24D2-OT/M2
RY726 VK438300 RELAY DH24D2-OT/M2
RY727 VK438300 RELAY DH24D2-OT/M2
* TE726 V4185300 TERM.SP 4P(UCRTA)
* TE726 V4185400 TERM.SP 4P(BG)
* TE727 V4185300 TERM.SP 4P(UCRTA)
* TE727 V4185400 TERM.SP 4P(BG)
* TE728 V4870200 TERM.SP 8P(UCRTA)
* TE728 V4870300 TERM.SP 8P(BG)
* TE729 V4870000 TERM.SP 4P(UCRTA)
* TE729 V4870100 TERM.SP 4P(BG)
VR501 VJ692700 VR.TRIM B330Ω
VR502 VJ692700 VR.TRIM B330Ω
VR503 VJ692700 VR.TRIM B330Ω
VR504 VJ692700 VR.TRIM B330Ω
VR505 VJ692700 VR.TRIM B330Ω
VR506 VJ692700 VR.TRIM B330Ω
VR507 VJ692900 VR.TRIM B680Ω
VR508 VJ692900 VR.TRIM B680Ω
V3750100 PIN L=50
BB071360 SCR.TERM 8.3x13
VK697600 SCR.BND.HD 3x10 SP ZMC2-Y
* V5001600 P.C.B. VIDEO(UC)
* V5001700 P.C.B. VIDEO(RT)
* V5001800 P.C.B. VIDEO(A)
* V5001900 P.C.B. VIDEO(BG)
CB1 VB858200 CN.BS.PIN 3P
CB2 VQ044700 CN.BS.PIN 16P
CB3 VD004500 CN.BS.PIN 2P
CB4 VD004600 CN.BS.PIN 3P
CB151 VQ963300 CN.BS.PIN 12P
CB152 VQ963300 CN.BS.PIN 12P
CB153 LB919030 CN.BS.PIN 3P
CB201 VF982300 CN.BS.PIN 17P
CB202 VQ960900 CN.BS.PIN 6P
CB261 VQ962700 CN.BS.PIN 6P
CB331 VQ961500 CN.BS.PIN 12P
CB332 VQ961500 CN.BS.PIN 12P
CB333 VQ961500 CN.BS.PIN 12P
CB334 VQ961500 CN.BS.PIN 12P
* CB901 V4477700 CN.SOCKET 16P
CB902 VQ047800 CN.BS.PIN 27P
CB904 VD004500 CN.BS.PIN 2P
C1 UB052100 C.CE.M.CHP 100pF 50V
C2 UB052100 C.CE.M.CHP 100pF 50V
C3 UB052100 C.CE.M.CHP 100pF 50V
C4 UB052100 C.CE.M.CHP 100pF 50V
C5 UB052100 C.CE.M.CHP 100pF 50V
C6 UB052100 C.CE.M.CHP 100pF 50V
C7 UB052100 C.CE.M.CHP 100pF 50V
C8 UB052100 C.CE.M.CHP 100pF 50V
C9 UB052100 C.CE.M.CHP 100pF 50V
C10 UB052100 C.CE.M.CHP 100pF 50V
* C11 UU147100 C.EL 10uF 25V
* C12 UU129100 C.EL 1000uF 10V
* C13 UU147100 C.EL 10uF 25V
* C14 UU129100 C.EL 1000uF 10V
* C15 UU137470 C.EL 47uF 16V
* C16 UU137470 C.EL 47uF 16V
C18 UB052820 C.CE.M.CHP 820pF 50V(ABG)
C18 UB053150 C.CE.M.CHP 1500pF 50V(UCRT)
* C19 UU127470 C.EL 47uF 10V
* C20 UU127470 C.EL 47uF 10V
* C21 UU127470 C.EL 47uF 10V
* C22 UU137470 C.EL 47uF 16V
* C23 UU137470 C.EL 47uF 16V
* C24 UU127470 C.EL 47uF 10V
* C25 UU127470 C.EL 47uF 10V
C26 UB052820 C.CE.M.CHP 820pF 50V
* C27 UU127470 C.EL 47uF 10V
C28 UB245100 C.CE.M.CHP 0.1uF 25V
